Hot-selling IP68 Fountain LED Light

Name: Hot-selling IP68 Fountain LED Light
Brand: Wilgex
Price: Negotiable

FOB Price

Negotiable / Piece

4 Pieces(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port Yantian shenzhen guangdong
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

LED Light Source:	Edison	Input Voltage(V):	24VDC	Lamp Power(W):	36
Lamp Luminous Flux(lm):	2880	Lamp Luminous Efficiency(lm/w):	80	Color Temperature(CCT):	Other, RGB
Working Temperature(℃):	-20, 60	Working Lifetime(Hour):	50000	IP Rating:	IP68
Certification:	CE, EMC, LVD, PSE	Lamp Body Material:	Aluminum	Place of Origin:	Guangdong, China
Brand Name:	Wilgex	Model Number:	WJ-LPL-36X1W-RGB-24V

Product Description

Different Angles of swimming pool underwater lights

Product Description

Features & Benefits

•Top grand waterproof rank:IP68

•Waterproof seal:silicone gasket

• Beautiful appearance design for our underwater led rope light

• Long lifespan >50000 hours

• Low voltage,safe for human

• Green light,environment friendly

• Low power consumption,high efficiency

• Various single color and RGB color available

• Good weather ability and pressure resistance

• Projection angle could be adjusted willingly with base stand

Applications

• The underwater led rope light is widely used in Swimming Pool, Fountain, Rearing Pond, Waterland, Artificial Waterfall.

Certificates

• CE,ROHS,PSE

Specifications

Physical Specifications
Dimension	D230*H190mm
Housing	Die-casting aluminum casing;tempered glass
Net weight	4.4KG
Rotary Angle	150°
IP Rating	IP68,underwater use or spot application

Electrical Specifications
Lighting Source	1W power LED
LED Quantity	36LEDs
Operation Temperature	-20°C~60°C(-4°F~140°F)
Input Voltage	24V DC
Power Consumption	36W
Control System	DMX512/4 wire 3 loop

Optical Specification
Chip type	Edison
Beam Angle	15°,30°,45°
Color	RGB(R-12,G-12,B-12)
Lighting Distance	40 meters

Two control methods for underwater led rope light

I: Connection Diagram for CTR-RGB-BOX controller

II: Directly Connecting to DMX Console,with internal DMX decoder

Different Size of underwater led rope light

Different sizes,wattage,LEDs number is available for our underwater led rope light

IP68 In Water Test

Lighting Effects for Underwater Led Pool Light

Certifications

Packaging for underwater led rope light
