mini 24V led underwater fountain light

Name: mini 24V led underwater fountain light
Brand: Wilgex
Price: Negotiable

FOB Price

Negotiable / Set

4 Sets(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port Yantian shenzhen guangdong
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

LED Light Source:	High power 1W Edison LEDs	Input Voltage(V):	24V	Lamp Power:	36
Lamp Luminous Flux(lm):	2880	Lamp Luminous Efficiency(lm/w):	80	Color Temperature(CCT):	Other, single color, Red, Yellow, Blue,Green, White, warm white etc
Working Temperature(℃):	-20, 60	Working Lifetime(Hour):	100000	Lamp Body Material:	Aluminum
IP Rating:	IP68	Certification:	CE, UL	Emitting Color:	Other, red, yellow, blue, green, white, warm white etc
Place of Origin:	Guangdong, China	Brand Name:	Wilgex	Model Number:	WJ-LPL-36x1W-24VDC

Product Description

Different Angles of swimming pool underwater lights

Product Description

Features & Benefits

•Top grand waterproof rank:IP68

•Waterproof seal:silicone gasket

• Beautiful appearance design for our underwater led rope light

• Long lifespan >50000 hours

• Low voltage,safe for human

• Green light,environment friendly

• Low power consumption,high efficiency

• Various single color and RGB color available

• Good weather ability and pressure resistance

• Projection angle could be adjusted willingly with base stand

Applications

• The underwater led rope light is widely used in Swimming Pool, Fountain, Rearing Pond, Waterland, Artificial Waterfall.

Certificates

• CE,ROHS,PSE

Specifications

Physical Specifications
Dimension	D230*H190mm
Housing	Die-casting aluminum casing;tempered glass
Net weight	4.4KG
Rotary Angle	150°
IP Rating	IP68,underwater use or spot application

Electrical Specifications
Lighting Source	1W power LED
LED Quantity	36LEDs
Operation Temperature	-20°C~60°C(-4°F~140°F)
Input Voltage	24V DC
Power Consumption	36W
Control System	DMX512/4 wire 3 loop

Optical Specification
Chip type	Edison
Beam Angle	15°,30°,45°
Color	RGB(R-12,G-12,B-12)
Lighting Distance	40 meters

Two control methods for underwater led rope light

I: Connection Diagram for CTR-RGB-BOX controller

II: Directly Connecting to DMX Console,with internal DMX decoder

Different Size of underwater led rope light

Different sizes,wattage,LEDs number is available for our underwater led rope light

IP68 In Water Test

Lighting Effects for Underwater Led Pool Light

Certifications

Packaging for underwater led rope light

Our Services

Our Promise: 1. Provide solutions and high quality products

2. Streamline the buying and paying processes

3. Deliver the goods to our customers all over the world with speed and precision

4. Protection of your sale area, ideas of design and all your private information

Our Service: 1. Provide professional person to communicate with you before the order.

2. Provide strict quality check for each part, each process before export.

3. Provide optimum system solution based on each client’s specific requirement.

4. Send extra accessories to help fix the lamp for free international express.

If accessories can’t solve the problem, we will send you the replacement lamp directly.
