1310nm 20km dual fiber fiber optic ethernet switch

FOB Price

USD $10 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 6000 Piece / Pieces per Month
Port Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

SH-328

Product Description

1310nm 20km dual fiber fiber optic ethernet switch

Product Description

SH-328 series 8+2 ports 10/100/1000M gigabit Ethernet optical switch converts 10/100/1000Base-T electrical signals with 1000Base-FX optical signals. The 8 Ethernet ports support 1536 byte long packet, and auto full/half duplex. The 12G backplane bandwidth lets it meet the various applications of LAN. It features flow control which can directly connect with router and server, as well as store-and-forward mode and auto learning of MAC address, which ensures the high reliability and low time delay. It provides options in multi mode/single mode fiber media, single fiber (WDM) or dual fiber, 220m~80km transmission distance, SC/FC/ST connector, SFP module…

Features

> Auto 10/100/1000Mbps, facilitating the network upgrading

> 12Gbps backplane bandwidth

> 8 ports 10/100/1000Base-Tx

> 2 ports 1000Base-Fx SFP slot

> Auto-sensed half duplex or full duplex

> Auto-sensed MDI or MDI-X

> Support the transmission of the long packet up to 9k

> Support IEEE802.3x flow control

> Options in single/multi mode, single/dual fiber, transmission distances and connectors

Specification

Item	Specifications
Data Rate	Copper: 10/100/1000Mbps; Fiber: 1000Mbps
Standard	IEEE802.3 10Base-T, IEEE802.3u,100Base-TX/FX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX, IEEE802.3x Flow Control
Wavelength	850nm/1310nm/1550nm
Transmission distance	MMF: 220/550m; SMF: 20~80km; Cat5: 100m
MAC address	1k
Buffer	512k
Backplane bandwidth	12G
Electrical Connector	4*RJ45
Fiber Connector	2*Duplex/simplex SC (ST or FC optional), LC (SFP Module) optional
LED indicator	PWR (power supply), FX 1/2 (Fiber link), TP1~8 1000M (Ethernet rate 1000M), TP1~8 L/A (TP cable link/act)
Power supply	DC 5V 2A
Power consumption	<6W
Operating temperature	-10~55℃
Operating humidity	90% max, non-condensing
Storage temperature	-40~70℃
Dimensions	228 (W) x 26 (H) x 108(L) (mm)

Product and Test

Ordering and Payment

Usual payment T/T Paypal etc, are availble . Cash also ok! In addition, Trade Assurance on Alibaba is also available.

Part Number	Description
SH-114M-02	410/100Base-T to 1100Base-F Fast Ethernet Optical Switch 850/1310nm, Multi-mode, SC, 2km, External power adaptor
SH-114S-xx	410/100Base-T to 1100Base-F Fast Ethernet Optical Switch 1310nm, Single mode, SC, External power adaptor xx: 20/40/60 (km)
SH-114S-xx	410/100Base-T to 1100Base-F Fast Ethernet Optical Switch 1550nm, Single mode, SC, External power adaptor xx: 80/100/120 (km)
SH-S114-xx	410/100Base-T to 1100Base-F Fast Ethernet Optical Switch 1310/1550nm, WDM, SC, External power adaptor xx: 20/40/60/80/100 (km)

Packaging & Shipping

Delivery time: 1-3 days for samples; 4-10 days for bulk orders.

Logistics mode chosen according to customers.

FAQ

1. Can you offer samples?

Yes, sample is available.

2. What's your lead time?

1-3 days for samples; 5-7 days for bulk order.

3. Certifications from you?

CE FCC RHOS etc.

4. Do you have MOQ?

There is no requirement for MOQ in SH LINK.

5. What's your price and quality?

SH LINK still do best to serve customers. Cost-effective products are supported! Let's talk more for details!
