Neutral packing 8*10/100/1000Base-T to 2*1000Base-F Gigabit 8 port media converter
SH-328 series 8+2 ports 10/100/1000M gigabit Ethernet optical switch converts 10/100/1000Base-T electrical signals with 1000Base-FX optical signals. The 8 Ethernet ports support 1536 byte long packet, and auto full/half duplex. The 12G backplane bandwidth lets it meet the various applications of LAN. It features flow control which can directly connect with router and server, as well as store-and-forward mode and auto learning of MAC address, which ensures the high reliability and low time delay. It provides options in multi mode/single mode fiber media, single fiber (WDM) or dual fiber, 220m~80km transmission distance, SC/FC/ST connector, SFP module…
> Auto 10/100/1000Mbps, facilitating the network upgrading
> 12Gbps backplane bandwidth
> 8 ports 10/100/1000Base-Tx
> 2 ports 1000Base-Fx SFP slot
> Auto-sensed half duplex or full duplex
> Auto-sensed MDI or MDI-X
> Support the transmission of the long packet up to 9k
> Support IEEE802.3x flow control
> Options in single/multi mode, single/dual fiber, transmission distances and connectors
Item |
Specifications |
Data Rate |
Copper: 10/100/1000Mbps; Fiber: 1000Mbps |
Standard |
IEEE802.3 10Base-T, IEEE802.3u,100Base-TX/FX, IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-SX/LX, IEEE802.3x Flow Control |
Wavelength |
850nm/1310nm/1550nm |
Transmission distance |
MMF: 220/550m; SMF: 20~80km; Cat5: 100m |
MAC address |
1k |
Buffer |
512k |
Backplane bandwidth |
12G |
Electrical Connector |
4*RJ45 |
Fiber Connector |
2*Duplex/simplex SC (ST or FC optional), LC (SFP Module) optional |
LED indicator |
PWR (power supply), FX 1/2 (Fiber link), TP1~8 1000M (Ethernet rate 1000M), TP1~8 L/A (TP cable link/act) |
Power supply |
DC 5V 2A |
Power consumption |
<6W |
Operating temperature |
-10~55℃ |
Operating humidity |
90% max, non-condensing |
Storage temperature |
-40~70℃ |
Dimensions |
228 (W) x 26 (H) x 108(L) (mm) |
Order Information
Part Number |
Description |
SH-114M-02 |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch |
SH-114S-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 20/40/60 (km) |
SH-114S-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 80/100/120 (km) |
SH-S114-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 20/40/60/80/100 (km) |
Payment
Packing and Delivery
FAQ:
1. Can you offer samples?
Yes, sample is available.
2. What's your lead time?
1-3 days for samples; 5-7 days for bulk order.
3. Certifications from you?
CE FCC ROHS.
4. What's your warranty?
Generally, 13 months.
