Simplex 10/100M single mode outdoor network switch
SH-114 series 4+1 ports 10/100M fast Ethernet optical switch converts 10/100Base-T electrical signals with 100Base-FX optical signals. It builds in 4-port 10/100M auto-sensed switch, adopts American top IC, high quality transceiver, providing the stable and reliable performance. It provides an economic way to extend the network transmission distance from 100m over copper cables to 120km over fiber optical cable. It provides options in multi mode/single mode fiber media, single fiber (WDM) or dual fiber, 2km~120km transmission distance, SC/FC/ST connector, etc. SH-114 series optical switch is widely used in telecommunication, transportation, security transmission...
> Auto 10Mbps and 100Mbps, facilitating the network upgrading
> Auto-sensed half duplex or full duplex
> Auto-sensed MDI or MDI-X
> Built-in high effective switching chip, ensuring the flow controlling,
cutting down the broadcasting packet
> 4 ports 10/100M auto sensed Ethernet ports, for backup and multiple-access
> Support the transmission of the long packet up to 1552 byte
> Low consumption, low heat dissipation, for long life span
> Options in single/multi mode, single/dual fiber, transmission distances and connectors
Item |
Specifications |
Data Rate |
Copper: 10/100Mbps; Fiber: 100Mbps |
Standard |
IEEE802.3 10Base-T, IEEE802.3u,100Base-TX/FX, IEEE802.3x Flow Control |
Wavelength |
850nm/1310nm/1550nm |
Transmission distance |
MMF: 2 km; SMF: 20~120km; Cat5: 100m |
Conversion means |
Store and Forward mode or Cut-Through mode |
Electrical Connector |
4*RJ45 |
Fiber Connector |
Duplex/simplex SC (ST or FC optional) |
LED indicator |
PWR (power supply), FX L/A(Fiber link/act), TP1/2/3/4 L/A (Ethernet Port 1/2/3/4 TP cable link/act) |
Power supply |
DC 5V |
Power consumption |
<3.5W |
Operating temperature |
-10~55℃ |
Operating humidity |
90% max, non-condensing |
Storage temperature |
-40~70℃ |
Dimensions |
112 (W) x 26 (H) x 85 (L) (mm) |
Net Weight |
250g |
Part Number |
Description |
SH-114M-02 |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch |
SH-114S-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 20/40/60 (km) |
SH-114S-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 80/100/120 (km) |
SH-S114-xx |
4*10/100Base-T to 1*100Base-F Fast Ethernet Optical Switch xx: 20/40/60/80/100 (km) |
There are 3 types of packing items in SH LINK.
1. Neutral packing without brand; 2. SH default packing; 3. OEM, let's talk more!
1. Can you offer samples?
Yes, sample is available.
2. What's your lead time?
1-3 days for samples; 5-7 days for bulk order.
3. Certifications from you?
CE FCC RHOS etc.
4. Do you have MOQ?
There is no requirement for MOQ in SH LINK.
5. What's your price and quality?
SH LINK still do best to serve customers. Cost-effective products are supported! Let's talk more for details!
