Flexible door manufacturer
Flexible lifting door Composed of lifting mechanism, a flexible door, conical spring clamping braking device, limit bit device,rails, beams and upright, electric control system, This form of gate has covers an area of small size, light weight, no rail, novel structure, wind resistance, sound insulation, thermal insulation characteristics, hoisting speed 6-18 meters per minute.
Flexible lifting door size:
Factory door position size: W13750×H14000 mm
flexible lifting door effective size:W13510×H12000 mm
Environment temperature:
1) Atmospheric temperature: annual average temperature: 15.5 °C
- i.Highest temperature: 45 °C
- Lowest temperature: -10 °C
- ii. Average temperature in summer: 27.8 °C 4
- average temperature in Winter: 4.8 °C
2) Average annual relative humidity 80 %
1. i. Max relative humidity in Summer:90 %
2. ii. Min relative humidity in Winter:60 %
3) Voltage: as your request
4)Environment at site:dust during shot blasting/peening environment(mainly for oxide coating),solvent gas get touches door when do paining.
The specifications of Flexible lifting door:
NO |
Name |
Unit |
Technical Parameter |
|
1 |
Lift weight |
t |
3.2(max) |
|
2 |
Lift height |
mm |
12000 |
|
3 |
Lift speed |
m/min |
3 |
|
4 |
The pulley ratio |
η |
1 |
|
5 |
Wirerope diameter |
mm |
18×19-¢14.5-1700 |
|
6 |
Reducer |
1:92.21 |
ZQD500+150-121.1-Z |
|
7 |
Brake motor |
kw |
YZR160M2-6-7.5KW |
|
8 |
Hydraulic brake |
kg |
YWZ-200/25 |
|
Trade mode: EXW,FOB ,CFR, CIF.
Payment term: 30% deposit by T/T, the balance paid before delivery or L/C at sight.
Delivery time: Within 20-60 days according to different type equipment.
Shandong Kaitai Dehumidifiers are delivered as a complete unit with fans, filters, rotor and controls. The dehumidifier is ready for site installation and connection to standard-size ducting.
Each dehumidifier will be custom designed according to the local conditions and the needs of the customer.
KAITAI are one Group company :Shandong Kaitai Group Co.,Ltd.
Branch company :Shandong Kaitai Shot Blasting Machinery Co.Ltd is for sand blasting room manufacturing.Specilizing in the production of sand blasting machine for over 15 years.Largest and professional manufacturer of shot blasting machine
in China.
Main market: South of America,North of America,Middle East,Australia,Asian,South of Asia.
Official website:/.
Branch company :Shandong Kaitai Industrial Technologies Co.Ltd is for abrasive manufacturing,its earlier name is:Shandong Kaitai Metal abrasive Co.Ltd,and these two names are still in using.
Official website:/.
Our factory address details is:Kaitai Road,Qingyang Town,Zouping county,Binzhou City,Shandong Province ,China.
1.Reply your inquiry in 24 hours.
2.Experienced staffs answer all your questions in time.
3.Customized design is available.
4.Exclusive and unique solution can be provided to our customer by our professional engineers and staff.
5.Special discount and protection of sales are provided to our distributor.
6.We are professional manufacturer of shot blasting Machine. Have a professional design team with more than 10 years de sign experience engineers, competitive with good quality
7.As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature.
8.Prompt delivery, site installation and commissioning.
Contact: Lina Zhu
Email:export19(at)
Mob:+0086-15154399965
Tel:+0086-531-88938987
Skype:kaitai lina
Whatapp:+8615154399965
For business negotiation,pls contact with us!
