Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Input Voltage(V):
12 / 24V DC
Lamp Power(W):
14.4
Lamp Luminous Flux(lm):
1080
Contact Supplier Request Quote Chat Now
Dongguan Wilgex Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Input Voltage(V) 12 / 24V DC
Lamp Power(W) 14.4
Lamp Luminous Flux(lm) 1080
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Other, color changing, digital, video, pixel
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
IP Rating IP65
Certification CE, PSE
Emitting Color Other, pixel, video, color changing
Base Type Other, 3 XLR professional connector
Place of Origin Guangdong, China
Brand Name WILGEX
Model Number WJ-NF-SMD5050-D-RGB-24V

 neon stripsneon strips







Product Description



 Features & Benefits

 •  Milky,Crystal and Colored PVC jacket design

•  Dome/Flat surface,continous and uniform illumination,no LED dot or dark spot.

•  Extremely flexible

•  100% waterproof ( IP65 and IP68 level)

•  100% breakage free

•  Low voltage or line voltage options

•  Durability,Impact Resistant

•  Weather Resistant , UV protection

•  Minimal heat output(Safe to the touch)

•  Longer life to 50,000 Hours

•  Easy to install(Cuttable on location)

•  Extremely low maintenance costs

•  80% less energy consumption of glass neon for Wilgex Latest design DMX digital SMD LED Neon Flex

•  Does not interfere with Video/Audio systems nearby

•  Available in all single colors,RGB colors & Digital RGB colors

•  2 years warranty



Parameter for Wilgex'sLED Neon Flex

Latest design SMD 2835  120PCS type LED neon flex--single color
Item No. WJ-NF-SMD2835-15*26mm WJ-NF-SMD2835-10*20mm
LED Type SMD 2835 SMD 2835
LED Spacing 0.83cm 0.83cm
LED qty/M 120pcs 120pcs
Input voltage 220V 110V 24V 12V 220V 110V 24V 12V
Cutting length 100cm 50cm 8.33cm 4.17cm 100cm 50cm 8.33cm 4.17cm
Watt/meter 9W/m 9W/m
Max.loading Length 100m 50m 20-25m 10-15m 100m 50m 20-25m 10-15m
LED color Red Green Blue Pink White Yellow Orange Purple Warm white
Lumen / m 233 388 156 158 450 228 235 158 340
Size 15x26mm 10x20mm

Latest design SMD 2835  96PCS type LED neon flex--single color
Item No. WJ-NF-SMD2835-15*26mm WJ-NF-SMD2835-10*20mm
LED Type SMD 2835 SMD 2835
LED Spacing 1.04cm 1.04cm
LED qty/M 96pcs 96pcs
Input voltage 220V 110V 24V 12V 220V 110V 24V 12V
Cutting length 100cm 50cm 12.5cm 6.25cm 100cm 50cm 12.5cm 6.25cm
Watt/meter 7W/m 7W/m
Max.loading Length 100m 50m 20-25m 10-15m 100m 50m 20-25m 10-15m
LED color Red Green Blue Pink White Yellow Orange Purple Warm white
Lumen / m 233 388 156 158 450 228 235 158 340
Size 15x26mm 10x20mm



Latest design SMD 5050 RGB type LED neon flex
Item No. WJ-NF-SMD5050-15*26mm WJ-NF-SMD5050-10*20mm
LED Type SMD 5050 SMD 5050
LED Spacing 0.83cm 0.83cm
LED qty/M 120pcs 120pcs
Input voltage 220V 110V 24V 12V 220V 110V 24V 12V
Cutting length 100cm 50cm 8.33cm 4.17cm 100cm 50cm 8.33cm 4.17cm
Watt/meter 12W/m 12W/m
Max.loading Length 100m 50m 10-20m 5-10m 100m 50m 10-20m 5-10m
LED color RGB RGB
Lumen / m 443 443
Size 15x26mm 10x20mm

Latest design SPI Digital 5050 type LED neon flex
Item No. WJ-NF-SMD5050-15*26mm WJ-NF-SMD5050-10*20mm
LED Type SMD 5050 SMD 5050
LED Spacing 1.67cm 1.67cm
LED qty/M 60pcs 60pcs
Input voltage 220V 110V 24V 12V 220V 110V 24V 12V
Cutting length - - 10cm 10cm - - 10cm 10cm
Watt/meter 12W/m 12W/m
Max.loading Length - - 8-10m 8-10m - - 8-10m 8-10m
LED color RGB RGB
Lumen / m 443 443
Size 15x26mm 10x20mm



 neon strips











Different Size and Shape Options for Our Color Jacket LED Neon


neon strips



neon strips

Control method for RGB LED Neon Flex--4 wires 3 loops

Available voltage:DC12V/24V



Votage:DC12V/24V connection diagram

 neon strips



Control Method for Digital RGB LED Neon Flex



I:   SPI control connection drawing:

neon strips

II: Directly DMX 512 programmes control connection drawing:

neon strips







Power connection drawing of Single Color LED Neon Flex

neon strips





Main Machine

neon strips



Application for LED Neon Flex



LED Neon Flex is widely used in city lighting engineering, architectural outline sketch, business travel façade decoration, billboards, taxi signing ballroom, stage, background production and a large number of places such as night scene decoration. neon strips



Certifications:

neon strips



Package:

neon strips



Our Services





Our Promise: 1. Provide solutions and high quality products

                      2. Streamline the buying and paying processes

                      3. Deliver the goods to our customers all over the world with speed and precision

                      4. Protection of your sale area, ideas of design and all your private information

Our Service: 1. Provide professional person to communicate with you before the order.

                     2. Provide strict quality check for each part, each process before export.

                     3. Provide optimum system solution based on each client’s specific requirement.

                     4. Send extra accessories to help fix the lamp for free international express.

                         If accessories can’t solve the problem, we will send you the replacement lamp directly.
