110V IP65 2 Wire LED Flex Neon

110V IP65 2 Wire LED Flex Neon thumbnail-1
110V IP65 2 Wire LED Flex Neon thumbnail-2
110V IP65 2 Wire LED Flex Neon thumbnail-3
110V IP65 2 Wire LED Flex Neon thumbnail-4
110V IP65 2 Wire LED Flex Neon thumbnail-5
110V IP65 2 Wire LED Flex Neon thumbnail-6
110V IP65 2 Wire LED Flex Neon photo-1
110V IP65 2 Wire LED Flex Neon photo-2
110V IP65 2 Wire LED Flex Neon photo-3
110V IP65 2 Wire LED Flex Neon photo-4
110V IP65 2 Wire LED Flex Neon photo-5
110V IP65 2 Wire LED Flex Neon photo-6
Negotiable MOQ: 100 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
Sanan
Input Voltage(V):
12,24,110,220
Lamp Power:
13
Contact Supplier Request Quote Chat Now
Dongguan Wilgex Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Sanan
Input Voltage(V) 12,24,110,220
Lamp Power 13
Lamp Luminous Flux(lm) 1040
Lamp Luminous Efficiency(lm/w) 80
Color Temperature(CCT) Other, all single color
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Lamp Body Material PVC
IP Rating IP65
Certification CE, PSE
Emitting Color Warm White
Place of Origin Guangdong, China
Brand Name Wilgex
Model Number WJ-NF-SMD5050-15*26-RGB

110V IP65 2 Wire LED flex Neon

110V IP65 2 Wire LED Flex Neon

110V IP65 2 Wire LED Flex Neon



Product Description

Features & Benefits

•  Milky,Crystal and Colored PVC jacket design

•  Dome/flat surface, continous and uniform illumination, no LED dot or dark spot.

•  Extremely flexible

•  100% waterproof ( IP65 and IP68 level)

•  100% breakage free

•  Low voltage or line voltage options

•  Durability, Impact Resistant

•  Weather Resistant, UV protection

•  Minimal heat output(Safe to the touch)

•  Longer life to 50,000 Hours

•  Easy to install(Cuttable on location)

•  Extremely low maintenance costs

•  80% less energy consumption of glass neon for Wilgex Latest design DMX digital SMD LED Neon flex wire

•  Does not interfere with Video/Audio systems nearby

•  Available in all single colors,RGB colors & Digital RGB colors

•  2 years warranty

Parameter

Latest design SMD 2835 type LED neon flex wire--single color
Item No.WJ-NF-SMD2835-15*26mmWJ-NF-SMD2835-10*20mm
LED TypeSan'an Brand SMD 2835San'an Brand SMD 2835
LED Spacing13.9mm13.9mm
LED qty/M72pcs72pcs
Input voltage230Vac110Vac24Vdc12Vdc230Vac110Vac24Vdc12Vdc
Cutting length100cm50cm8.33cm4.17cm100cm50cm8.33cm4.17cm
Watt/meter9W/m9W/m9W/m9W/m
Max.loading Length100m50m15~20m8~10m100m50m15~20m8~10m
LED colorRed, Green, Blue, Yellow, Orange, Purple, Pink, White, Warm white
Size15x26mm10x20mm
Latest design SMD 2835 type LED neon flex wire--single color
Item No.WJ-NF-SMD2835-15*26mmWJ-NF-SMD2835-10*20mm
LED TypeSan'an Brand SMD 2835San'an Brand SMD 2835
LED Spacing10.4mm10.4mm
LED qty/M96pcs96pcs
Input voltage220Vac110Vac24Vdc12Vdc220Vac110Vac24Vdc12Vdc
Cutting length100cm50cm12.5cm6.25cm100cm50cm12.5cm6.25cm
Watt/meter9W/m9W/m9W/m9W/m
Max.loading Length100m50m15~20m8~10m100m50m15~20m8~10m
LED colorRed, Green, Blue, Yellow, Orange, Purple, Pink, White, Warm white
Size15x26mm10x20mm
Latest technology SMD5050 type LED Neon flex wire -- RGB Color
Item No.WJ-NF-SMD-RGB-15*26mmWJ-NF-SMD-RGB-10*20mm
LED TypeSan'an Brand SMD5050San'an Brand SMD5050
LED Spacing13.9mm13.9mm
LED qty/M72pcs72pcs
Input voltage220Vac110Vac24Vdc12Vdc220Vac110Vac24Vdc12Vdc
Cutting length100cm50cm8.33cm4.17cm100cm50cm8.33cm4.17cm
Watt/meter13W/m13W/m13W/m13W/m
LED colorSeven colors changing, fading
Max.loading Length100m50m15~20m8~10m100m50m15~20m8~10m
Size15x26mm10x20mm
Unique design Digital RGB Magic color SMD5050 LED Neon flex wire-SPI control
Item No.WJ-NF-SMD-RGB-15*26mm-SPI
LED TypeSan'an Brand SMD5050
LED Spacing15.6mm16.7mm
LED qty/M64pcs60pcs
Pixel4 LEDS/Pixel, 16 Pixels/M 6 LEDS/Pixel, 10 Pixels/M
LED ColorMagic color changing (DMX DIY available )
Input voltage12V DC24V DC
Cutting length6.25cm10cm
Watt/meter13W/m13W/m
Max. Loading Length8~10m10~15m
LM/M
Brightness		12.5%: 56.8LM,  25%: 100.8LM, 37.5%: 143.2LM,
50%: 187.80LM, 62.5%: 231.6LM, 75%:276.5LM, 87.5%:320.3LM, 100%: 368.2LM
Size15x26mm
Latest design SMD2835 type 360 Degree D25mm Round LED Neon flex wire--single color
Item No.WJ-NF-SMD2835-D25-72x2WJ-NF-SMD2835-D25-96x2
LED TypeSan'an Brand SMD 2835San'an Brand SMD2835
LED Spacing13.9mm10.4mm
LED qty/M144 pcs192 pcs
Input voltage220V AC110V AC24V DC12V DC220V AC110V AC24VDC12V DC
Cutting length100cm50cm8.33cm4.17cm100cm50cm12.5cm6.25cm
Watt/meter13W/m13W/m
LED colorRed, Green, Blue, Yellow, Orange, Purple, Pink  White, Warm white
Max.loading Length100m50m10~20m5~8m100m50m12~15mm6-8m
SizeDia 25mmDia 25mm

Different Size and Shape Options for Our LED Neon flex wire Color Jacket

110V IP65 2 Wire LED Flex Neon

Comparison of Old DIP led neon flex with New SMD led neon flex wire



DIP LED Neon flex wireSMD LED Neon flex wire
110V IP65 2 Wire LED Flex Neon110V IP65 2 Wire LED Flex Neon
Connection

Control method for RGB LED Neon flex wire--4 wires 3 loops

Available voltage:DC12V/24V,AC 110V-120V,AC 220V-230V

I: Votage:DC12V/24V connection diagram

 110V IP65 2 Wire LED Flex Neon

II: Voltage:AC110-120V,or AC 220V-230V

110V IP65 2 Wire LED Flex Neon

Control Method for Digital RGB LED Neon flex wire

I: SPI control connection drawing:

110V IP65 2 Wire LED Flex Neon

II: Directly DMX 512 programmes control connection drawing:

110V IP65 2 Wire LED Flex Neon



Power connection drawing of Single Color LED Neon flex wire

110V IP65 2 Wire LED Flex Neon

Application

Application

    Latest design DMX digital SMD LED Neon flex wire is widely used in city lighting engineering,architectural outline sketch,business travel façade decoration,billboards,taxi signing ballroom,stage,background production and a large number of places such as night scene decoration.

110V IP65 2 Wire LED Flex Neon

Packaging & Shipping

We do inspection after manufacuture as well as before packing


110V IP65 2 Wire LED Flex Neon



Company Information

    Dongguan Wilgex Lighting Co., Ltd was established in year 2003. We are specialized in developing, designing and manufacturing LED decorating and lighting proodcuts for more than 12 years.

    Our products assortment includes LED neon flex, LED wall washer, LED underwater / fountain / pool light, and LED undergroud light as well as garden lights.

    All of our products are manufactured to the highest industry standards and utilize some of the best quality components available such as San'an, Edison and CREE LEDs, and MeanWell Power Supplies and are backed by a conservative 2 Year Warranty. All of our products are CE (EMC, LVD, EMF) and RoHS certified and can reach to IP65, IP68 waterproof grade.
