100w Car and Home Input 100-240v 50/60 hz Adaptor From Saige Market

YH-8100 2 IN 1 Specification:

1

Model

AC

DC

2

Rated Input Voltage

110V/230V 50Hz/60Hz

12V

3

Input Voltage Range

100V-240V 45Hz-65Hz

11V-14V

4

Output Power

100W

100W

5

Input Rated Current

1.14A

10A

6

Input Power

114W

120W

7

Output Current

12V/15/16/18/19V

5.26A MAX

8

20V/24V

4.17A MAX

9

Output Voltage

12/15/16/18/19/20/24V

0~+0.5V NO LAOD

10

12/15/16/18/19/20/24V

±0.3V Rating LOAD

11

USB Output:5V DC

1.0A MAX

12

Efficiency

over 88%(TYP)

13

Short circuit Protection

YES

14

Overload protection

YES

15

Ripple Noise

500mV

16

Line Regulation

1%

17

Load Regualtion

1%

Advantage

Environment Requirement

1

USB charger function

1

Operating Temperature

0°C to 40°C

2

Stablized output,low ripple&low interference

2

Humodity

20% to 80%

3

Adjustable output voltage

3

Storage Temperature

-10°C to 70°C

4

High efficiency&low energy consumption

4

Storage Humidity

10% to 90%

Universal distribution DC plug

Series Num

Outside path

Inside path

length

1

6

3.2/1.4

13

2

6.3

3

13

3

5.5

3

12

4

5.5

2.1

12

5

5.5

1.7

12

6

4.8

1.7

11

7

4

1.7

11

8

3.5

1.35

11
