fiberglass geogrid, geogrid machine, geogrid
Specification of Geogrid
Introduction of geogrid
1. Geogrid is made of high molecular polymer after extruded and laminated and punched into regular mesh before longitudinal stretching.
2.This process makes high molecule in direct line state in oblong oval net structure with uniform distribution and high node intensity.
3.This structure has rather high tensile strength and stretch modulus, especially our products of this kind have superior world class tensile strength and stretch modulus with extensibility between 2% and 5%The soil offers ideal force carrying and diffusing chain system.
4.It has large tensile strength (>150Mpa), and is suitable for different kindsof soil. It is a prevailing reinforcement material.
Features of fiberglass geogrid, geogrid machine, geogrid
1. Enhance roadbed and effectively diffuse its load to improve its stability and bearing capacity and increase service life;
2. Be able to bear more alternate load;
3. Prevent roadbed distortion and crack caused by the loss of roadbed materials;
4. Increase the self-supporting property of fill behind retaining wall, decrease the earth pressure of retaining wall, save cost, increase service life and reduce maintenance expense;
5. Combine anchor sprouting concrete construction method to give side slope maintenance, which not only saves investment by 30%-50% but also reduces erection time by one time or above.
6. To increase geogrid in the roadbed and surface of highways can reduce flexure, track and put off the flawing appearance by 3-9 folds and reduce the thickness of structural layer by 36%
7. It is applicable to any kind of soil, not necessary to draw material from other place, saving time and labor;
8.Simple and rapid construction will greatly reduce construction cost
Our main products about geogrid
1. (self-adhesive) Fiberglass geogrid: tensile strength from 30kn/m to 400kn/m, elongation less than 3%, mesh size 12.7mm or 25.4mm or 50mm, coated by asphalt (bitumen), max roll width 6m, roll length 50m or 100m, packed by black PE membrane + plastic pipe. With CE certificate.
2.Polyester geogrid: tensile strength from 20kn/m to 1000kn/m, elongation less than 13%, mesh size 12.7mm or 25.4 mm or 50mm, coated by PVC (water soluble PVC or oil PVC max roll width 6m, roll length 50m or 100m, packed by black PE membrane + plastic pipe. With CE certificate.
3.Geocomposites: fiberglass geogrid ---tensile strength from 30kn/m to 200kn/m, elongation less than 3%,mesh size 12.7mm or 25.4 mm or 50mm, coated by asphalt (bitumen), max roll width 6m, roll length 50m or 100m, packed by black PE membrane + plastic pipe. polyester non-woven geotextile-------white color, unit weight often 150g/sqm. Composited by adhesive glue or by sewing. With CE certificate.
4.Mine Grid: tensile strength from 40kn/m to 800kn/m, used under mine for support and protecting, white or yellow color.
With China patent and MA certificate.
At the same time, we also export PP biaxial geogrid, HDPE uniaxial geogrid, HDPE geocell, Non- woven geotextile, Geonet, Geomat, GCL.
