WW1325M 3 Axis CNC Stone Engarving Machine
1. Overview
Stone Engarving Machine is suitable for Curb & Paving Stone Forming industries, Stone processing factories, Tombstone processing industries, Advertisement industries for Stone art craft works, Home & Outdoor Product making industries, Architectural decoration industries and so on.
2. Advantages
1.) Stone Engarving Machine's bed is welded by the thick wall steel seamless tube, high temperature tempering treatment, high rigidity, bearing strength better
2.)Dual motor drive for Y-axis, moving stably.
3.)Good software compatibility, suitable for Type3, Artcam, Castmate, UcanamV9
4.)Constant spindle motor power, strong cutting strength, high efficiency.
5.)High precision rack transmission, fast speed.
6.)Imported linear square guide way, double row four row slider, high precision, long life time.
7.)Well selected electrical accessory, let the failure rate to the minimum
8.)With water and automatic water supply and cooling system
9.)Dustproof and waterproof design, better to protect the machine driving part.
3. Applications
Except for stone work. The Stone Engarving Machine is mainly designed for woodworking, any kinds of glass. aluminium, brass, metal material processing work.
1.) Granite, Marble, Bluestone, Sandstone and other stone engraving
2.) Hard stone like Granite can be layered engraved to reach 3mm
3.) Marble, Bluestone and so on can be engraved to 5mm each time
4. Performance Parameter
| Number | Description | Parameter |
| 1 | X,Y,Z Working Area | 1300x2500x200mm |
| 2 | Table Size | 1360×2940mm |
| 3 | X,Y,Z Traveling Positioning Accuracy | ±0.03/300mm |
| 4 | X,Y,Z Repositioning Accuracy | ±0.03mm |
| 5 | Frame | Welded Structure |
| 7 | X, Y Structure | Rack and Pinion Drive, Hiwin Rail Linear Bearings |
| 8 | Z Structure | Hiwin Rail Linear Bearings and Ball Screw |
| 9 | Max. Engraving Speed | 3000mm/min |
| 10 | Spindle power | 4.5 Or 6KW |
| 14 | Drive Motors | Stepper System |
| 15 | Working Voltage | AC380V/50/60Hz,3PH (Option: 220V)) |
| 16 | Command Language | G Code |
| 17 | Operating System | DSP System (options: Ncstudio/Mach3 PC Software) |
| 18 | Computer Interface | USB |
| 19 | Flash Memory | 128M(U Disk) |
| 21 | X,Y Resolution | <0.03mm |
| 22 | Software Compatibility | Type3/UcancameV9 Software (Option: Artcam software) |
| 23 | Running Environment Temperature | 0 - 45 Centigrade |
| 24 | Relative Humidity | 30% - 75% |
| 25 | Packing Size | 3200X1960X1870mm |
5. Details
6.Certificate
7. Packing&Delivery
8. Guarantee & After Sales Service
- The Stone Engarving Machine is guaranteed for 12 months.
- Technical support by phone, e-mail or MSN around the clock.
- Friendly English version manual and operation video CD disk.
9. Factory
10. Contact US
1.How about the delivery time?
Normal 3axis CNC Engraving machine-within 2weeks.
ATC CNC Engraving machining center-within 4weeks.
4axis CNC Engraving machine-within 50days.
5axis CNC Router-within 6months.
2.What kind of payments do you support?
T/T.L/C ,other kinds please contact with us.
3.What’s the MOQ?
For whole machine, MOQ=1.
4.Can you produce according to customer’s design?
Sure ,we are professional manufacturer ,OEM are also welcome.
5.Can you tell me your main customers?
That’s our customer’s privacy ,we should protect their information.
At the same time, please rest assured that your information is also safe here.
6.Consult
We will recommend the most suitable machine to you after being informed by your requirements, such as the main jobs you wanna the machine to process, the materials you will wanna to process, the working area you want, the max cutting thickness, etc.
