Factory Price & Super Quality Corrugated Aluminum Sheet 1050/1060/1100
1.Chemistry Data :
Aluminum 99.6 min
Copper 0.05 max
Iron 0.35 max
Magnesium 0.03 max
Manganese 0.03 max
Remainder Each 0.03 max
Silicon 0.25 max
Titanium 0.03 max
Vanadium 0.05 max
Zinc 0.05 max
Physical Data :
Density (lb / cu. in.) 0.0975
Specific Gravity 2.705
Melting Point (Deg F) 1200
Modulus of Elasticity Tension 10
Modulus of Elasticity Torsion 3.85
Principal Design Features
This is a relatively low strength, essentially pure aluminum, alloy.
It is noted for excellent weldingcharacteristics and formability along with good corrosion resistance.
It cannot be hardened by heat treatment.
Machinability
The machinability of AL 1060 is fair to poor, especially in the soft temper conditions.
In the harder (cold worked) tempers such as H16 and H18 the machining characteristics are improved.
Either carbide or high-speed steel tooling may be used and use of lubricants is recommended, although some cutting may be done dry.
Forming
This alloy has excellent forming capability by cold or hot working with commercial techniques.
Welding AL 1060 may be welded by standard commercial methods. If filler rod is required it should be of AL 1060. A precaution should be noted for the use of resistance welding as by this method some trial and error experimentation may be required to obtain good results.
Heat Treatment
This alloy does not harden by heat treatment. It may be annealed after cold working. See "Annealing".
Forging
This alloy may be forged in the temperature range of 950 to 700 F.
Hot Working
Hot working, if required, may be done in the range of 900 to 500 F.
Cold Working
The cold working characteristics of AL 1060 are excellent. It can readily be cold worked by all conventional methods.
Annealing
Annealing may be done at 650 F followed by air cooling.
Aging
Not applicable to this alloy.
