3105/3005 PE/PVDF color coated aluminum coil for shutter
Specifications:
v Alloy:1050/1060/1100/3003/3004/3005/5052/5754/6062
v Base Material :PPG/ aluminum sheet
v Thickness: 0.3mm~3.0mm
v Width: ≤1850mm
v Length : as you like
v Weight: 2.5 MT-9MT
v Coil ID: 75mm, 150mm, 200mm, 300mm, 400mm, 508mm or negotiable
v Zinc Coating:50~200g/m2
v Painting method: PCM printing,2 color coating and 2 baking,
no color difference, extreme flatness technique method
v Frontispiece painting: KYNAR500 fluorocarbon resin painting
( more than 70% fluorocarbon resin)
v The thickness of coating: ≥30μ
v Protective layer: PE≥80μ
v Gloss requirement: 20%~60%.
v Color: according to the customer’s requirements
v Pattern: Wood imitation, Marble, Brush Brick, and Camouflage series, etc
Paint: PE , PVDF.
Application
Wine bottles, Pilfer-proof caps, ROPP cap, Pharmaceutical cap, etc
Chemical stability | |
Acid resistance |
No change within 7 days in 10%HCL |
No change within 7 days in 10%H2SO4 | |
Alkali resistance |
No change within 7days in 10% NaOH |
Solvent reistance |
No change within 200 times( butanone) |
Boil water resistance |
No change within 24 hours |
Resistance to humidity |
No change at 100% humidity,35℃ temperature within 2000 hours |
Oil resistance |
No change within 24 hours |
Brush resistance |
Not less than 10000 times,no change |
Pencil hardness |
Not less than 2H |
Coating impact resistance |
5J |
Coating flexibility |
Not less than 2T |
Color deviation |
≤2 |
Henan Zhongxin Aluminum Co.,Ltd is a professional Aluminum manufacture which has 30 years experiences for manufacturing aluminum sheet, coil, and foil in China.
Our main products include: various alloy of aluminum plate, strip, foil, color-coated aluminum coil, aluminum sheet circle, ginning aluminum plate, aluminum and copper strip/foil for dry type transformer.The products are widely used in areas including electric power, transportation, construction decoration, aerospace, packaging materials, electronic appliances, etc.
If you want to see more products of our company, you can surf our website: or zxly.en.china.cn
Whenever you need more info, please don't hesitate to contact mewith telling the thickness*width*length, alloy no.&temper, color, quantity,other details including package. I'll reply your email within 2 days.
