T-30A 30W triple output switching power supply,power supply for led
- 50000 Piece / Pieces per Month
- Ningbo/Shanghai
- Credit Card
- ME Series Modules High Stability High Voltage Power Supply for Microchannel Plates
- MMC Series DC High Stability Voltage Power Supply for Microchannel Plates (100V-600V,0.1W)
- Brand new power box 640C0022G01 York control system motherboard power supply GLC75D-CVG
- Power Supplies TVD1.3-15-03 Original Stock
- 10W 2.5KV Isolation Wide Input AC/DC Converters
- 30W Wide Voltage Input DC/DC Converters power supply
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Minsen | Model Number: | T-30A |
Output Power: | Other, 30W | Output Type: | Triple | Input Voltage: | Other, 110V-220VAC |
Output Voltage: | 5V | Output Current: | 3A |
Product Description
Specifications
High quality triple output switch power supplyModel | D-30A | D-30B | D-30C | ||||
output | DC voltage | CH1:5V | CH2:12V | CH1:5V | CH2:24V | CH1:12V | CH2:24V |
Voltage tolerance | ±2% | +3%~-7% | ±2% | +4%~-6% | ±2% | +5%~-7% | |
Rated current | 4A | 1A | 2.2A | 1A | 1A | 1A | |
Current range | 0.5~4A | 0.2~1A | 0.4~2.2A | 0.1~1A | 0.3~1A | 0.1~1A | |
Rated power | 32W | 35W | 36W | ||||
Ripple&noise | 80mvp-p | 100mvp-p | 80mvp-p | 120mvp-p | 100mvp-p | 120mvp-p | |
DCvoltage ADJ.range | CH1:-9%~+10% | ||||||
input | Voltage range | 90~132VAC/180~264VAC(selected by switch),255~373VDC | |||||
frequency | 47~63HZ | ||||||
AC current | 0.8A/115VAC,0.45A/230VAC | ||||||
efficiency | 73% | 75% | 77% | ||||
Inrush current | Cold start current 18A/115VAC,36A/230VAC | ||||||
Leakage current | < 2mA/240VAC | ||||||
protection | overload | Rated output power110%~150 start over load protection | |||||
protection type :part layer type current limit ,auto-recovery after fault condition is removed | |||||||
----- | ----- | ||||||
----- | |||||||
environment | Working temp,humidity | -10°C~+60°C,20%~90%RH | |||||
Storagetemp,humidity | -20°C~+85°C,10%~95%RH non-condensing | ||||||
Withstand vibration | 10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes | ||||||
safety | Withstand voltage | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | |||||
Isolated resistance | I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC | ||||||
Fitstandard | Safety standard | Fit UL1012 | |||||
EMC standard | Fit EN55022,CLASSA | ||||||
others | Dimension | 129*98*38mm (L*W*H) | |||||
Weight/packing | 0.4kg/45pcs/19kg/0.034m³/1.2CUFT | ||||||
note | 1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25°C of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.. |
