30w 12v 2.5a Din Rail Power Supply
US$ 2 - 30
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Minsen, Minsen
Model Number:
DR-30-12
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
30W 12V 2a 24V 1.5a Din Rail Power SupplyUS$ 2.99 - 7.99MOQ: 10 Pieces -
CE Standard Din Rail Switch Power Supply 30w 45w 60w 75w 100w 120w 240wUS$ 2 - 11.55MOQ: 1 Piece
-
CE Standard 30w Din Rail Switch Power Supply 30w DR-30-24US$ 2 - 11.55MOQ: 1 Piece
-
CE Standard Din Rail Switching Mode Power Supply 30w 45w 60w 75w 100w 120w 240wUS$ 2 - 11.55MOQ: 1 Piece
-
CE Standard 30w Din Rail Switching Mode Power Supply 30wUS$ 2 - 11.55MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
Minsen, Minsen
Model Number
DR-30-12
Output Power
1 - 50W
Output Type
Single
Input Voltage
Other, 110-220v
Output Voltage
12V
Output Frequency
47-63Hz
Output Current
2.5A
Specifications
1,30W Din Rail power supply2,High quality and low working temperature
3,CE ROHS certificated
4,OEM is welcomed
Model :30w Din Rail power supply DR-30W-12V 2.5A
Specification:
1,With CE,ROHS,ISO9001 certificates
2,OEM,ODM are allowed.
3,Warrabty:2years.
4,For more detail information ,please feel free to contact us and we would appreciate for your asking.
5,We would provide the best service and your satisfaction is our top glory.
6,looking forward your enquiry.
7, 30w Din Rail power supply DR-30W-12V 2.5A
| MODEL | DR-30-5 | DR-30-12 | DR-30-15 | DR-30-24 | |
| OUTPUT | DC VOLTAGE | 5V | 12V | 15V | 24V |
| RATED CURRENT | 3A | 2A | 2A | 1.5A | |
| CURRENT RANGE | 0 ~ 3A | 0 ~ 2A | 0 ~2A | 0 ~ 1.5A | |
| RATED POWER | 15W | 24W | 30W | 36W | |
| RIPPLE & NOISE (max.) | 80mVp-p | 120mVp-p | 120mVp-p | 150mVp-p | |
| VOLTAGE ADJ. RANGE | 4.75 ~ 5.5V | 10.8 ~ 13.2V | 13.5 ~ 16.5V | 21.6 ~ 26.4V | |
| VOLTAGE TOLERANCE | ±2.0% | ±1.0% | ±1.0% | ±1.0% | |
| LINE REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| LOAD REGULATION | ±1.0% | ±1.0% | ±1.0% | ±1.0% | |
| SETUP, RISE TIME | 100ms, 30ms/230VAC 100ms, 30ms/115VAC at full load | ||||
| HOLD TIME(Typ.) | 100ms/230VAC 30ms/115VAC at full load | ||||
| INPUT | VOLTAGE RANGE | 85 ~ 264VAC 120 ~ 370VDC | |||
| FREQUENCY RANGE | 47 ~ 63Hz | ||||
| EFFICIENCY (Typ.) | 74% | 81% | 82% | 83% | |
| AC CURRENT | 0.88A/115VAC 0.48A/230VAC | ||||
| INRUSH CURRENT(max.) | COLD START 15A/115VAC 30A/230VAC | ||||
| PROTECTION | OVERLOAD | 105 ~ 160% rated output power | |||
| Protection type : Constant current limiting,recovers automatically after fault condition is removed | |||||
| OVER VOLTAGE | 5.75 ~ 6.75V | 13.8 ~ 16.2V | 17.25 ~ 20.25V | 27.6 ~ 32.4V | |
| Protection type : Shut down o/p voltage,re-power on to recover | |||||
| ENVIRONMENT | WORKING TEMP. | -20 ~ +60ºC (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing | ||||
| STORAGE TEMP., HUMIDITY | -20 ~ +85ºC , 10 ~ 95% RH | ||||
| TEMP. COEFFICIENT | ±0.03%/ºC (0 ~ 50ºC) | ||||
| VIBRATION | 10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes | ||||
| SAFETY & EMC | SAFETY STANDARDS | Design refer to UL60950-1,TUV EN60950-1,EN50178 | |||
| WITHSTAND VOLTAGE | I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC | ||||
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC | ||||
| EMI CONDUCTION & RADIATION | Compliance to EN55022 (CISPR22) Class B | ||||
| HARMONIC CURRENT | Compliance to EN61000-3-2,-3 | ||||
| EMS IMMUNITY | Compliance to EN61000-4-2,3,4,5; ENV50204, EN55024, Light industry level, criteria A | ||||
| OTHERS | MTBF | 441.5K hrs min. MIL-HDBK-217F (25ºC) | |||
| DIMENSION | 78*93*56mm (L*W*H) | ||||
| PACKING | 0.27Kg; 48pcs/14Kg/1.02CUFT | ||||
