Help CenterCE Standard 12v 2a 5v 2a Power Supply 12v 2a 5v 2a D-30
Related Products
-
CE Standard 12v 2a 5v 2a Power SupplyUS$ 2 - 8MOQ: 1 Piece -
CE Standard DUAL 12v 2a 5v 2a Power SupplyUS$ 2 - 8MOQ: 1 Piece
-
Hot Selling 60W Single Output Switching Power SupplyUS$ 3.99 - 10.99MOQ: 100 Pieces
-
Power Supply 120w Cctv Dual Switching Power SupplyUS$ 0.99 - 8.99MOQ: 10 Pieces
-
60W Dual Output Switching Power Supply 5v 12vUS$ 2.99 - 8.99MOQ: 10 Pieces
Specifications
1.Dual output switching power supply 5v 12v2.with CE certificate and more are under way
3.High quality and competitive price
Dual output switching power supply
About D-30W series
*.we have models D-30A, D-30B , D-30C about 30W single output dual output switching power supply
*Model D-30A (5v4a) (12v 1a )/(12V2A ,5V 2A)
*Model D-30B ( 5v2.2a) (24v 1a)
*Model D-30C (12v1a) (24v 0.5a)
*.we are manufacturer specialized in making switching power if you want these models or any other kinds of power supply models ,we can make them for you .
*With CE certificate ,so you can trust our quality and servece .And the price is competitive.
Specifications
Dual output switching power supply 5v 12v
1.Universal AC input:Full range
2.Protections:short circuit/overload/over voltage/over temperature
3.100% full load burn-in test
4.Low cost,high reliability
5.1 year warranty
6. Size:129*98*38mm
7 .Weight:0.45Kg
8.Dual output switching power supply 5v 12v
Index Type |
D-30A |
D-30B |
||
DC Voltage |
5V |
12V |
5V |
24V |
Voltage Adjust Range |
4.75-5.5V |
|
4.75-5.5V |
|
Voltage Tolerance |
±2% |
+3%-7% |
±2% |
+3%-5% |
Rated Current |
4A |
1A |
2.2A |
1A |
Current Range |
0.54A |
0.1A |
0.5-2.2A |
0.1-1A |
Rated Power |
32W |
35W |
||
Efficiency |
72% |
74% |
||
Ripple&Noise(Max.) |
50mvp-p |
100mvp-p |
50mvp-p |
100mvp-p |
Line Regulation |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
Load Regulation |
±0.5% |
±4% |
±1% |
±4% |
Voltage Range |
85-132VAC/170-264VAC 47-63Hz 240-370VDC |
|||
Ac Current |
0.8A/115V 0.45A/230V |
|||
Inrush Current(Max.) |
cold start current 18A/115V 36A/230V |
|||
Leakage Current |
<1mA/240V |
|||
Overload Protection |
105-150% Type :Current limitation auto recovery |
|||
Over-voltage Protection |
-- |
|||
Over-temperature Protection |
-- |
|||
Temp.Coefficient |
±0.03%/°C(0-50°C) |
|||
Setup.Rise,Hold Time |
200ms 100ms 300ms /230V |
|||
Withstand Voltage |
I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC |
|||
Isolated Resistor |
I/P-O/P,I/P-FG,O/P-FG:500VDC/100MΩ |
|||
|
|
|||
Weight |
0.45Kg |
|||
