Brian Desmond polycarbonate hollow sheet
Polycarbonate hollow sheet is a new kind of building material, which is strength, heat insulation and good light_transmission. Due to their excellent advantages, such as high impact resistance, good head good insulation, sound insulation, light weight, flame resistance , weather resistance,easy cutting ,good machining capability and strong plasticity.
Hot sale
| Thickness(mm) | Weight(kg/m2) | Mini-bending radius(mm) | With(m) | Length(m) | Colour |
| 1.1 | 1.32 | 234 | 1.22-2.1 | no limited | Clear, Green, Blue ,Brown ,Opal ,Red ,Yellow. |
| 2 | 2.4 | 360 | 1.22-2.1 | ||
| 3 | 3.6 | 540 | 1.22-2.1 | ||
| 4 | 4.8 | 720 | 1.22-2.1 | ||
| 5 | 6 | 900 | 1.22-2.1 | ||
| 6 | 7.2 | 1080 | 1.22-2.1 | ||
| 8 | 9.6 | 1440 | 1.22-2.1 | ||
| 10 | 12 | 1800 | 1.22-2.1 | ||
| 12 | 14.4 | 2250 | 1.22-2.1 | ||
| 15 | 18 | 2700 | 1.22-2.1 |
Technical Parameters
| Impact strengh | Transparency | Specifc grevity | Coefficient of thermal expansion | Service temperayure | Heat conductivity |
| 2.1j/m-2.3j/m | 40%-80% | 1.2g/cm³ | 0.065mm/m°C | -40°C—120°C | 3.0-3.9w/m²°C |
| Tensile strengh | Flexural strengh | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break |
| ≥60N/mm | 100N/mm² | 2400Mpa | 10mm two laminates reduced 10db | ≥65Mpa | >100% |
Our advantages:
1. Makrolon PC resin from Bayer in Germany.
2. ISO 9001:2008 & ISO 14001:2004 proved.
3. UV co-extrusion for long life-span
4. Customized colors and dimensions up request.
Features:
1) High light transmission: over 82%
2) Excellent impact resistance: 80 times of same thick glass.
3) Weather and UV resistant_properties retained for years.: Temperature resistance range is -40°C ~ +120°C, with an ultraviolet coextruded film on the sheet surface. It can prevent the resin fatigue or yellowing caused by the ultraviolet.
4) Light weight: only 1/12 of the weight of glass of the same thickness. It can be easily cold bent as well as thermal shaping.
5) Flame resistance: High fire performance rating is class B1.
6) Sound and heat insulation: Superb sound insulation for freeway barrier and super thermal insulation save energy.
7) An engineering plastic of excellent integration capability. It has outstanding physical, mechanical, electrical and heat capabilities.
Application:
1) Building/House skylights
2) Work shop/storehouse skylight
3) Roofing
4) Carports
5) Indoor partition
6) Cover of greenhouse
7) Cover of swimming pool
Note:
1.We will offer you price referring to your detail request,so please kingdy inform w the thickness,size,color and other requirements you prefer,and the special offer will be given.
2.We can produce various polycarbonate sheet & PE films as per requirments of necessary,we can also give some advice for reference.
3.The pictures above just for your reference.
4.Sample is FREE
