Brian Desmond polycarbonate solid sheet
specifications
UV coating embossed polycarbonate sheet
1. 1.6mm-16mm
2. Lexan/Bayer virgin material
3. UV protect and 10yrs warranty
4. ISO,RoHS
Conventional Color : transparent, blue-green, light-green, blue, light-opal, bronze(brown), etc.
| Thickness(mm) | Weight(kg/m2) | Mini-bending radius(mm) | With(m) | Length(m) | Colour |
| 1.1 | 1.32 | 234 | 1.22-2.1 | no limited | Clear, Green, Blue ,Brown ,Opal ,Red ,Yellow. |
| 2 | 2.4 | 360 | 1.22-2.1 | ||
| 3 | 3.6 | 540 | 1.22-2.1 | ||
| 4 | 4.8 | 720 | 1.22-2.1 | ||
| 5 | 6 | 900 | 1.22-2.1 | ||
| 6 | 7.2 | 1080 | 1.22-2.1 | ||
| 8 | 9.6 | 1440 | 1.22-2.1 | ||
| 10 | 12 | 1800 | 1.22-2.1 | ||
| 12 | 14.4 | 2250 | 1.22-2.1 | ||
| 15 | 18 | 2700 | 1.22-2.1 |
Technical Parameters
| Impact strengh | Transparency | Specifc grevity | Coefficient of thermal expansion | Service temperayure | Heat conductivity |
| 2.1j/m-2.3j/m | 40%-80% | 1.2g/cm³ | 0.065mm/m°C | -40°C—120°C | 3.0-3.9w/m²°C |
| Tensile strengh | Flexural strengh | Modulus of elasticity | Effect of sound insulation | Tensile stress at break | Elongation at break |
| ≥60N/mm | 100N/mm² | 2400Mpa | 10mm two laminates reduced 10db | ≥65Mpa | >100% |
Our advantages:
1. Makrolon PC resin from Bayer in Germany.
2. Advanced UV-PC coextrusion lines (5 lines).
3. ISO 9001:2008 & ISO 14001:2004 proved.
4. UV co-extrusion for long life-span
5. Customized colors and dimensions up request.
Application
Note:
1.We will offer you price referring to your detail request,so please kingdy inform w the thickness,size,color and other requirements you prefer,and the special offer will be given.
2.We can produce various polycarbonate sheet & PE films as per requirments of necessary,we can also give some advice for reference.
3.The pictures above just for your reference.
4.Sample is FREE
FAQ
1. Are you manufacturer or Trade Company?
We are a professional factory to produce polycarbonate sheets, founded in 2007.
2. What's the order process?
a. Inquiry---provide us all clear requirements.
b. Quotation---official quotation form with all clear specifications.
c. Printing file--- PDF, Ai, CDR, PSD, the picture resolution required at least 300 dpi for private Label printing( OEM)
d. Sample confirmation--- mass production begins prior to the appoval of samples.
e. Payment terms--- T/T 30% in advanced, balanced before shipment.
f. Production---mass production
g. Shipping--- by sea, air or courier.
3. What terms of payment you use?
T/T, PayPal, Western Union
