Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead

W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead

W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead thumbnail-1
W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead thumbnail-2
W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead photo-1
W7 Large Format Printer 3.2m on Konica Minolta 1024 Printhead photo-2
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Solvent printer, inkjet printer
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
HongKong AD Solution Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, Solvent printer, inkjet printer
Place of Origin Guangdong, China
Brand Name WinJET
Model Number W7-KM1024-42PL-4H
Usage Other, outdoor solvent printer
Automatic Grade Semi-Automatic
Voltage 220V
Gross Power AC100-120V/AC220-240V(Adaptive)
Dimensions(L*W*H) L4,810 x W1010 x H1520mm
Weight 540kgs

WinJET SOLVENT PRINTER



Product Description

 Model: W7-KM1024-42PL-4H

Printhead: KM1024 42pl

Printing Quality: 360dpi
Printing Speed:
Draft Mode 180X720dpi 2pass @ 83sqm/h
Production Mode 240X720dpi 2pass @ 66sqm/h
Quality Mode 240X1080dpi 3pass @ 42sqm/h

RIP Software: PhotoPRINT 10.5 or Maintop V5.30



W7 large format printer 3.2m on Konica Minolta 1024 printhead



Product Name WINJET W7 SOLVENT PRINTER
Maximum Print
Width		 3200mm (10.5ft)
Printing Resolution 360DPI (Physical) 720DPI (Physical)
Output (sqm/h)   W7-KM1024/42PL-4H W7-KM512/42PL-8H W7-KM512/42PL12H   W7-KM1
024/14PL
-4H		 W7-KM5
12/14PL-
4H		 W7-KM5
12/14PL-
8H
Print Mode Output Speed (sqm/h) Print Mode Output Speed (sqm/h)
180x720dpi 2pass 83 83 124.5 360x360dpi2pass 52 26 52
240x720dpi 2pass 66 66 99 720x720dpi 2pass 45.6 22.8 45.6
180x1080dpi 3pass 54 54 81 360x1080dpi3pass 34 17 34
240x1080dpi 3pass 42 42 63 720x1440dpi 4pass 22.6 11.3 22.6
180x1440dpi 4pass 42 42 63 720x1080dpi 6pass 15.4 7.7 15.4
240x1440dpi 4pass 33 33 50 720x1440dpi 8pass 11.4 5.7 11.4
Ink Type K42 Low Solvent Ink K14 Eco Solvent Ink
Ink Color 4 Colors( C , M , Y , K ) / 6 Colors(C , M, Y, K, LC, LM)
Ink Capacity 5L Per Main Tank of Each Color
Ink Supply System Low Ink Detector, Auto or Manual Ink Supply System
Media Width 3300mm (10.8ft)
Media Type Vinyl,Flex,Polyester,Back-lit Film, Window Film,etc
Auto Media Feed
System		 Equipped (Max. Media Weight 120kg )
Auto Cleaning System Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System Equipped (Drying System Optional)
Clamp Equipped
Print Interface USB2.0
Printhead Height 2 to 4 mm Above Media Adjustable
RIP Software PhotoPRINT 10.5 or Maintop V5.30
Input Power AC 220V ,50Hz
Operation Temperature: 20~28℃ Humidity: 40%~60%
Machine
Dimension		 L4,601 x W884 x H1,303 mm; Net Weight: 540Kgs (1,190lbs)
Package
Dimension		 L4,810 x W1010 x H1550mm; Gross Weight: 680Kgs (1,499lbs); Two units in one 20 feet container



  W7 large format printer 3.2m on Konica Minolta 1024 printhead
