ALL CATEGORIES

ONE WAY VISION

Negotiable MOQ: 5000 Square Meters (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

OEM

Model Number:

ONE WAY VISION

HongKong AD Solution Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name OEM

Model Number ONE WAY VISION

Specifications

ONE WAY VISION

TECHNICAL DATA SHEET

ONE WAY VISION

Item	Unit	Value	Test Method
Thickness - film	µm	140	GB/T6672-2001
Thickness - finished product	µm	330	GB/T6672-2001
Adhesive weight	g/m²	13	FINAT12
Elongation at break MD	%	≥40	GB/T1040.1-2006
Elongation at break CD	%	≥30	GB/T1040.1-2006
Dimensional stability MD	%	≤0.6	FINAT14
Dimensional stability CD	%	≤0.4	FINAT14
Initial Adhesion	N/25mm	≥5	Finat9
180 Peel - 20 minutes	N/25 mm	≥7	Finat1
180 Peel - 24 hours	N/25 mm	≥11.5	Finat1
Tensile Strength at break MD	N/25 mm	≥20	GB/T1040.1-2006
Tensile Strength at Break CD	N/25 mm	≥15	GB/T1040.1-2006
Applied Printers	HP, ROLAND, MIMAKI, VUTEK, NUR, SCITEX, DGI, etc.
LOW CADMIUM & HEAVY METALS	We can reach: EN71-3
Conclusions and Announcements	Declaration: Please choose products suitably according to relative provisions or industrial standards. The company bears the responsibility for the specified technical and performance data on this page only. The company is not responsible for any other liability. (The technical data on this page is calculated on average, and ±5% tolerance is acceptable) Remarks : ‘G’represents Glossy surface , Glossy or Matte could be made as requirements
