ftth catv china price mini folding receiver china price mini folding strong receiver
Key Features
1. Excellent optical AGC control technique, when the input optical power range is -9~+2dBm, the output level, CTB and CSO basically unchanged;
2. Downlink working frequency extended to 1GHz, RF amplifier part adopts the high performance low power consumption GaAs chip, the highest output level up to 112dBuv;
3. EQ and ATT both use the professional electric control circuit, makes the control more accurate, operation more convenient;
4. Built-in the national standard II class network management responder, support remote network management (optional);
5. Compact structure, convenient installation, is the first choice equipment of FTTB CATV network;
6. Built-in high reliability low power consumption power supply, and selectable external power supply;
Applications
Specifications
Item |
Unit |
Technical Parameters |
||
Optical Parameters | ||||
Receiving Optical Power |
dBm |
-9 ~ +2 |
||
Optical Return Loss |
dB |
>45 |
||
Optical Receiving Wavelength |
nm |
1100 ~ 1600 |
||
Optical Connector Type |
|
SC/APC or specified by the user |
||
Fiber Type |
|
Single mode |
||
Link Parameters | ||||
C/N |
dB |
≥ 51 |
Note 1 |
|
C/CTB |
dB |
≥ 60 |
||
C/CSO |
dB |
≥ 60 |
||
RF Parameters | ||||
Frequency Range |
MHz |
45 ~860/1003 |
||
Flatness in Band |
dB |
±0.75 |
||
|
ZBR1001J (FZ110 output) |
ZBR1001J (FP204 output) |
||
Rated Output Level |
dBμV |
≥ 108 |
≥ 104 |
|
Max Output Level |
dBμV |
≥ 108 (-9 ~ +2dBm Optical power receiving) |
≥ 104 (-9 ~ +2dBm Optical power receiving) |
|
≥ 112 (-7 ~ +2dBm Optical power receiving) |
≥ 108 (-7 ~ +2dBm Optical power receiving) |
|||
Output Return Loss |
dB |
≥16 |
||
Output Impedance |
Ω |
75 |
||
Optical AGC Range |
dBm |
(-9dBm/-8dBm/-7dBm/-6dBm/-5dBm/-4dBm)—(+2dBm) adjustable |
||
Electrical control EQ range |
dB |
0~15 |
||
Electrical control ATT range |
dBμV |
0~15 |
||
General Characteristics | ||||
Power Voltage |
V |
A: AC (150~265)V |
D: DC 12V/1A External power supply |
|
Operating Temperature |
℃ |
-40~60 |
||
Consumption |
VA |
≤ 8 |
||
Dimension |
mm |
190 (L)* 110 (W)* 52 (H) |
||
Packaging & Shipping
Packaging Details:15pieces/carton, Optical Fiber Product can be OEM/ODM
We can design some special packaging according to customer's requirement.
Delivery Details:3~5 days after receipt of deposit for little orders.
Before Sale Service:professional offer detailedproducts test report related specifications
Contract Manufacturing: OEM Service Offered design service offered buyer Label Offered
Shanghai Yogel Communication Equipment Co.,Ltd. welcome to visit our factory!
The core of Yogel is honesty and efficiency.pls feel free to contact us.
Your inquiry is expected! Warmly welcom you to inquiry us for this product.
