Marine diesel engine (G128 series) SDEC new products
- 5000 Piece / Pieces per Month
- ShangHai port or ZhongShan port
- T/T
- Hydraulic steel wire spiral reinforced industrial rubber hose from China
- Corrosion resistant wire spiral hydraulic rubber hose
- Steel Wire Spiral Heavy Duty Used Rubber Hose
- best quality wire braid hydraulic rubber hose HH581
- Fine processing wire spiral hydraulic rubber hose HH681
- high performance wire spiral rubber hose
Product Details
Place of Origin: | Shanghai, China | Brand Name: | ShangHai diesel engine(SDEC) | Model Number: | SC15G460Ca2 |
Type: | Other, marine diesel engine |
Product Description
Main product: diesel engine,diesel generator,alternator and spare part.
Diesel engine Usage:widely used for generator set,boat,wheel loader,water pump ,sand pump,fire pump,etc:
Brief introduction
The G series in-line diesel engine is improved on the basic of the G128 XinLong marine diesel engine,The G series engine has been upgrated significantly in reliability ,fuel economy,NVH(Noise,Vibration,Harshness) and appearance.The SC15G engine’s stroke is extended to 165mm.
Engine Model | G128ZLCa15 | SC15G460CA2 |
Type | Six cylinder,In line,direct injection,water cooled | |
Aspiration | Turbocharged and intercooled | |
Bore*Stroke(mm) | 135*150 | 135*165 |
Displacement(L) | 12.8 | 15 |
Compression ratio | 17:1 | |
Rated power/speed(kw/rpm) | 267/1800 | 308/1500 |
Max torque/speed(N.m/rpm) | 2300 | |
Min fuel consumption(g/kw.h) |
198
| |
Oil consumption(g/kw.h) | ≤0.4 | |
Starting type | Electric start(DC24V) | |
Dimension(mm) | 1680*884*1550 | |
Net Weight(kg) | 1350 | |
Certificate | CCS+IMOII,ISO9001:2000 | |
Application | Marine main propulsion engine |
Relevant products:
Series | Model | Type | Rated Power/speed (kw/rpm) | Bore*Stroke (mm) | Aspiration | Displace-ment(L) | Application |
G128 | G128ZCa | In line, direct injection 4 stroke Water cooled Six cylinder | 162/1500 | 135*150 | Turbocharged | 12.8 | Marine main Propulsion engine |
G128ZCa1 | 162/1800 | ||||||
G128ZLCa | 189/1500 | Turbocharged AndAftercooled
| |||||
G128ZLCa3 | 187/1800 | ||||||
G128ZLCa1 | 200.5/1500 | ||||||
G128ZLCa2 | 236/1500 | ||||||
G128ZLCa12 | 236/1800 | ||||||
G128ZLCa5 | 267/1500 | ||||||
G128ZLCa15 | 267/1800 | ||||||
G128ZCaF1 | 165.3/1500 | Turbocharged | Marine auxiliary engine | ||||
G128ZLCaF2 | 165.3/1800 | ||||||
G128ZLCaF | 187/1500 | Turbocharged And Aftercooler | |||||
G128ZLCaF1 | 200.5/1500 | ||||||
G128ZLCaF2 | 242.4/1500 | ||||||
G128ZLCaF3 | 278.8/1500 | ||||||
SC15G | SC15G420CA2 | 280/1500 | 135*165 | Turbocharged And Aftercoole | 15 | Marine main Propulsion engine | |
SC15G460CA2 | 308/1500 | ||||||
SC15G500CA2 | 330/1500 | ||||||
SC15G500.1CA2 | 330/1800 | ||||||
SC15G500CF2 | 330/1500 | Marine auxiliary engine | |||||
|
|
|
|
|
|
|
|
