Main product: diesel engine,diesel generator,alternator and spare part.
Diesel engine Usage:widely used for generator set,boat,wheel loader,water pump ,sand pump,fire pump,etc:
Brief introduction
The G series in-line diesel engine is improved on the basic of the G128 XinLong marine diesel engine,The G series engine has been upgrated significantly in reliability ,fuel economy,NVH(Noise,Vibration,Harshness) and appearance.The SC15G engine’s stroke is extended to 165mm.
Engine Model |
G128ZLCa15 |
SC15G460CA2 |
Type |
Six cylinder,In line,direct injection,water cooled |
|
Aspiration |
Turbocharged and intercooled |
|
Bore*Stroke(mm) |
135*150 |
135*165 |
Displacement(L) |
12.8 |
15 |
Compression ratio |
17:1 |
|
Rated power/speed(kw/rpm) |
267/1800 |
308/1500 |
Max torque/speed(N.m/rpm) |
2300 |
|
Min fuel consumption(g/kw.h) |
198
|
|
Oil consumption(g/kw.h) |
≤0.4 |
|
Starting type |
Electric start(DC24V) |
|
Dimension(mm) |
1680*884*1550 |
|
Net Weight(kg) |
1350 |
|
Certificate |
CCS+IMOII,ISO9001:2000 |
|
Application |
Marine main propulsion engine |
|
Relevant products:
Series |
Model |
Type |
Rated Power/speed (kw/rpm) |
Bore*Stroke (mm) |
Aspiration |
Displace-ment(L) |
Application |
G128 |
G128ZCa |
In line, direct injection 4 stroke Water cooled Six cylinder |
162/1500 |
135*150 |
Turbocharged |
12.8 |
Marine main Propulsion engine |
G128ZCa1 |
162/1800 |
||||||
G128ZLCa |
189/1500 |
Turbocharged AndAftercooled
|
|||||
G128ZLCa3 |
187/1800 |
||||||
G128ZLCa1 |
200.5/1500 |
||||||
G128ZLCa2 |
236/1500 |
||||||
G128ZLCa12 |
236/1800 |
||||||
G128ZLCa5 |
267/1500 |
||||||
G128ZLCa15 |
267/1800 |
||||||
G128ZCaF1 |
165.3/1500 |
Turbocharged |
Marine auxiliary engine |
||||
G128ZLCaF2 |
165.3/1800 |
||||||
G128ZLCaF |
187/1500 |
Turbocharged And Aftercooler |
|||||
G128ZLCaF1 |
200.5/1500 |
||||||
G128ZLCaF2 |
242.4/1500 |
||||||
G128ZLCaF3 |
278.8/1500 |
||||||
SC15G |
SC15G420CA2 |
280/1500 |
135*165 |
Turbocharged And Aftercoole |
15 |
Marine main Propulsion engine |
|
SC15G460CA2 |
308/1500 |
||||||
SC15G500CA2 |
330/1500 |
||||||
SC15G500.1CA2 |
330/1800 |
||||||
SC15G500CF2 |
330/1500 |
Marine auxiliary engine |
|||||
|
|
|
|
|
|
|
|
