Product Details
Place of Origin: | Shanghai, China | Brand Name: | yogel | Model Number: | optical fiber cross connection cabinet |
Product Description
optical fiber cross connection cabinet for outdoor fiber access network
Key Features
- Box is with all—weather protection can withstand accidents or vicious destruction.
- Can be realized the direction through of fiber cable and disk storage functions.
- . If weld integration module was used ,welding wiring can be set out to operate in the outside of the box.
- All of the positive operation ,with the provisional table to facilitate the operation ,easy to maintain.
- Adapter installation of 35°ramps to ensure that fiber radius of curvature is larger than 40mm ,avoiding arc to shoot eyes directly.
- Card-fit installation of FC SC applied to strip and non-ribbon cable.
- Being with fixing,stripping and grounding protection device of a reliable optical cable.
- To provide all kinds of accessories,to avoid the accidents of fiber by mechanical damage.
- Fiber distribution and dispatch are all positive operation.
Applications
OCC is used for fiber access networks in the trunk cable and wiring of fiber optic cable connecting node equipment. It is mainly used for outdoor cable connections, wiring and scheduling, activities and, through optical fiber connectors and jumper cable and fiber optic cable will be the core of the flexible connectivity.
GXF5-254 series of OCC holds excellent performance, secure, reliable, flexible scheduling core, applied to optical fiber LAN, regional fiber optic network and access network, and so on.
Box was made by high-intensity SMC unsaturated polyester anti-corrosion special synthetic material, high-performance insulation can withstand drastic changes in climate and poor working conditions.
Specifications
Function: | FTTH Cable splicing distribution |
Splitter type: | customized |
Splitter installation position: | customized |
Adaptor type: | SC/FC/PC |
Max ratio: | 24 cores |
Fiber Type | Corning SMF-28TM,9/125µm |
Splice tray quantity: | 1pc |
Cable: | Drop cable, outdoor cable, standard indoor cable |
Dimension | 1450*750*540mm(L*W*H) |
Optional accessory: | Simplex SC/FC adapters |
Installation method | Wall mounted or pole mounted,outdoor or indoor use |
Accessories | Keys,plastic expansion screw,self-tapping screws,hose clamps,shrinkable sleeves,etc. |
Packaging Details
One pieces/one bag
(We can design some special packaging according to customer's requirement)
The length of patch cord is depend on user's requirements can be OEM and ODM
Delivery Detail
5~7 days after receipt of deposit for little orders
Shanghai Yogel Communication Equipment Co.,Ltd.
welcome to visit our factory!
Fast delivery |
Competitive price |
Reliable quality, OEM service available |
Prompt answer for any question or inquiry |
Steady quantities supply, Strict quality control |
Professional product and technical support |
advanced technology and anefficient management team |
Excellent OWIRE or your own brandbox/roller design and package |
We can provide goodservices on logistic andother help you may need |
Yogel mainly specializes in developing and manufacturing optical fiber patch cord and optic communication equipment,WDM, CWDM, DWDM, optical switch, circulator, isolator, adaptor,attenuator,conector,patchcable,loopbacks, Optical Equipments,Etc.
The core of Yogel is honesty and efficiency.our company has been audited and approved ISO9001,CE. For any question,pls feel free to contact us.Your inquiry is expected! Warmly welcom you to inquiry us for this product.
The special injection molding process provide each connecion greater durability in resisting pull ,strain and impacts from cabling installs on the other hand each cable is 100%optically inspected and tested for insertion loss before you receive it .It also have great performance in immune to electrical interference .
Shanghai Yogel Communication Equipment Co., Ltd was founded in July,2012. (The former company was founded in 2004). The whole team has over 60 technical and management staffs with Master and Bachelor degree, and nearly 200 employees.The company invariably focus on production,sales and technology service of fiber optics products.
