ZZX-200 Fiberglass double sided tape 0.2mm/soft and compressible
- 1000 Square Meter / Square Meters per Month
- Shenzhen China
- T/T Credit Card
-
Wenzhou Yika 7.2KV High Voltage Fuse 63 Amp
-
3240 Epoxy Board, High-quality Insulation Material, Flexible Customization, Widely Applicable 3240 Epoxy Sheet
-
Chinese Factory Electrical Insulation Brown 3025 Phenolic Bakelite Resin Cotton Cloth Fabric Laminate Board Sheet Phenolic Board
-
4x8 fiberglass sheets g10 epoxy glass fiber board g10 material
-
Factory Price Bakelite Decorative HPL Press plates bakelite sheet
-
Black G10 Sheet - High Quality Carbon Fiber G10 FR4 Sheets - Precision-made PCB Materials
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | ZZX | Model Number: | ZZX-200 |
| Type: | Insulation Tape | Material: | Fiberglass | Application: | High Voltage |
| Rated Voltage: | 4000V | Tensile Strength: | Good |
Product Description
ZZX-200 Fiberglass double sided tape 0.2mm/soft and compressible
Features
.Thermally conductive
. Electrically isolating
. Soft and compressible
. Wide temperature compliance
. Strong sticky adhesive
. REACH, RoHS & UL compliant
Applications
. Electronic devices
. LED lightings
. Printings
. Hardware
. Power supply
. Others
Designed Size Offered
.Customized die cutting
Physical Properties:
Thickness | Unit(mm) | 0.15 | 0.20 | 0.25 | 0.30 |
Color | / | White | white | white | white |
Specific Gravity | G/cm3 | 1.8 | 1.8 | 1.8 | 1.8 |
Thermal conductivity | W/M.K | 1.2 | 1.2 | 1.2 | 1.2 |
Heat Resistance | ℃in2/W | 0.68 | 0.70 | 0.72 | 0.74 |
Breakdown Voltage | VAC/mm | 3200 | 4000 | 5000 | 5000 |
Application Temperature | ℃ | -40~+120 | -40~+120 | -40~+120 | -40~+120 |
Peel Adhesion | N/25mm | 10.2 | 12 | 14 | 16.4 |
Tack | N/25mm | 12 | 14.3 | 16.5 | 18.2 |
