High low temperature resistance Thermal paste thermal conductivity
Features
.Thermal conductivity: 2.0/3.0/5.0 W/M-K
. Low thermal resistance
. RoHS & UL compliance
Applications
. CPU and Chipset cooler
. Switching mode power
. Electronic Home compliance
. LED industry
. Others
Store Method:
. This item can be saved for 18 months when it is sealed under room temperature 25°C.
Thermal conductive silicone grease, this product with good thermal conductivity and insulating properties of metal oxides with the silicone compound into a paste. Product has excellent heat conductivity, good electrical insulation, wide working temperature (operating temperature:-50 ° c ~+200 ° c), good stability, low consistency and good construction performance, this product is non-toxic, corrosive, odorless, not dry, not dissolved.
Products can be use in any electronic product ,Such as the CPU and heat sink to fill gaps, high power triode, diode thruster components, and base materials (aluminum, copper) contact at the crack of heat transfer media.
Physical Properties:
PROPERTY |
G-200 |
G-300 |
G-500 |
TEST METHOD |
UNIT |
Density |
2.3 |
2.7 |
3.2 |
ASTM D792 |
--- |
Color |
Gray |
Gray |
Gray |
--- |
Visual |
Volatile Content |
0.5 |
0.3 |
0.2 |
ASTM E595 |
%/Wt |
Thermal Conductivity |
2.0 |
3.0 |
5.0 |
ASTM D5470 |
W/mK |
Thermal Resistance |
0.041 |
0.025 |
0.009 |
ASTM D5470 |
C-In2/W |
Breakdown Voltage |
1100 |
1000 |
600 |
ASTM D149 |
VAC/mil |
Dielectric Constant |
4.5 |
4.7 |
4.8 |
ASTM D150 |
--- |
Volume Voltage |
>1013 |
>1013 |
>1012 |
ASTM D257 |
--- |
Work Temp |
-50°C to 200°C |
||||
About Us:
Welcome to contact us and ask for more details!
Send Inquiry to This Supplier
