Product description:
ZZX N-300 Thermal conductive mud good thermal conductivity
Thermal conductive mud is silicon resin based which is made by adding thermal conductive materials and adhesive materials. It is used to fill the gap between electronic components and heat sinks so that lower the thermal resistance to realize the dropping of the temperature of electronic elements quickly and effectively, thus lengthen the using life of electronics.
Features: Applications: 1.No settlement, stored at room temperature Integrated chip
2.Excellent resistance to high and low Car electronic products
temperature , excellent resistance to weather Controller
3.Radiation resistance and excellent dielectric properties Telecommunications Equipment
4.Excellent chemical and stability mechanical Power modules
5.Low stress, low modulus thermal products
6.Has plasticity like plasticine , easy to operate
7.Suitable for the product design which require big
variation in the thickness
Physical properties:
Property |
N-100 |
N-200 |
N-300 |
Test method |
Unit |
Density |
1.0 |
2.0 |
3.0 |
ASTM D792 |
-------- |
Color |
White |
Gray |
Gray |
------- |
Visual |
Thermal conductivity |
1.0 |
2.0 |
3.0 |
ASTMD5470 |
W/m-K |
Thermal resistance |
0.004 |
0.003 |
0.001 |
ASTM D5470 |
C-In²/W |
Breakdown voltage |
1100 |
1000 |
1000 |
ASTM D149 |
VAC/mil |
Dielectric constant |
4.5 |
4.7 |
4.8 |
ASTM D150 |
------- |
Volume voltage |
>1013 |
>1013 |
>1012 |
ASTM D257 |
------- |
Work temp |
-50℃ to 200℃ |
||||
