XL5036CL more efficiency more creativity milling machene
- 1000 Set / Sets per Month
- Qingdao
- T/T
- CNC Milling Machines,Mini CNC Milling Machines,DIY CNC Milling Machines,Hobby CNC Milling,DIY milling
- Small CNC Milling Machine for School, Hobbist,Prototype,DIY
- YORNEW Desktop CNC Lathe Machine, education cnc, vocation cnc, hobby cnc, diy cnc
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
- Industrial 4.0 intelligent manufacturing production line, FMS, CIM, training system
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | YOURONGXILI |
Model Number: | XL5036CL | Type: | Vertical | CNC or Not: | Normal |
Voltage: | 380V | Power(W): | 5500 | Dimension(L*W*H): | 2520*2100*2150 |
Weight: | 3000kg | Certification: | CE ISO | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. Driven by Ac servo motor2. Table automatic feed on X,Y,Z
3. Automatic rapid feed X,Y,Z
XL5036CL more efficiency more creativity milling machene
Specification | Unit | XL5032 | XL5032C | XL5032CL |
Table size | mm | 1325X320 | 1600X320 | |
T-slots(NO./Width/Pitch) |
| 3/18/70 | ||
Longitudinal travel | mm | 750 | 1100 | 1300 |
Cross travel | mm | 320 | ||
Vertical travel | mm | 460 | 450 | |
Table feed (X/Y/Z) | mm/min | 30-750/20-500/15-375 8 steps | ||
Table rapid speed(X/Y/Z) | mm/min | 1200/800/600 | ||
Spindle taper |
| 7:24 ISO50 | ||
Spindle speed range | r.p.m | 50-1475 | ||
Spindle speed step | steps | 12 steps | ||
Spindle travel | mm | 70 | ||
Max. swivel angle of vertical milling head |
| ±30° | ||
Distance between spindle nose and table surface | mm | 50-510 | 50-500 | |
Distance between spindle axis and column guideway | mm | 378 | ||
Torque of X/Y/Z axis AC servo motor | N.m | 10 | ||
Main motor Power | kw | 5.5 | ||
Overall dimensions (L×W×H) | mm | 1800×2100×2150 | 2245×2100×2150 | 2520×2100×2150 |
Net weight | kg | 2750 | 2850 | 2900 |
