Ball Screw Driven Vertical Knee Style Milling Machine
US$ 15,000 - 18,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
YOURONGXILI
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Vertical Knee Style Mill MachiningUS$ 15,000 - 18,000MOQ: 1 Set -
Driven by Ballscrew Vertical Knee Mills MachiningUS$ 10,000 - 12,000MOQ: 1 Set
-
Knee-Type Milling Machine X5032NegotiableMOQ: 1 Set
-
Vertical Knee-Type Milling Machine X5032NegotiableMOQ: 1 Set
-
Universal Heavy Duty Milling Machine With Digital ReadoutUS$ 15,000 - 18,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
YOURONGXILI
Model Number
X5040
Type
Vertical
CNC or Not
Normal
Voltage
380V
Power(W)
11kw
Dimension(L*W*H)
2556 x 2159 x 2298
Weight
4250KG
Certification
CE ISO
Warranty
12 MONTHS
After-sales Service Provided
Engineers available to service machinery overseas
Ball screw driven vertical knee style milling machine X5040
Specification |
Unit |
X5040 |
Table size |
mm |
400X1700 |
T-slots(NO./Width/Pitch) |
|
3/18/90 |
Longitudinal travel(manual/auto) |
mm |
900/880 |
Cross travel(manual/auto) |
mm |
315/300 |
Vertical travel(manual/auto) |
mm |
385/365 |
Rapid feed speed(X/Y/Z) |
mm/min |
2300/1540/770 |
Max. load |
kg |
800 |
Table feed range(X/Y/Z) |
mm/min |
23.5-1180/15-786/8-394 |
Spindle speed range |
r/min |
30-1500 |
Spindle speed step |
steps |
18 steps |
Stroke of spindle quill |
mm |
85 |
Max.swivel angle of vertical milling head |
|
±45° |
Distance between spindle nose and table surface |
mm |
115/500 |
Power of spindle motor |
kw |
11 |
Overall dimensions(L×W×H) |
mm |
2556×2159×2258 |
Net weight |
kg |
4250/4350 |
