Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > XLK5030 Utmost Precision Fanuc Cnc Knee Style Milling Machene
XLK5030 Utmost Precision Fanuc Cnc Knee Style Milling Machene
US$ 15,000 - 25,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Yourongxili
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XK5040 CNC Metal Working MachineUS$ 15,000 - 25,000MOQ: 1 Set -
XLK5032CL Cnc Milling Machine With 4 AxisUS$ 15,000 - 25,000MOQ: 1 Set
-
XLK5032C Cnc Milling Machine With 4 AxisUS$ 15,000 - 25,000MOQ: 1 Set
-
X6132 Manual Universal Milling Machine PriceUS$ 3,000 - 5,000MOQ: 1 Set
-
Ballscrews Milling Machine With Universal Milling HeadUS$ 10,000 - 11,000MOQ: 1 Set
Condition
New
Place of Origin
Shandong, China
Brand Name
Yourongxili
Model Number
XLK5030
Type
Vertical
CNC or Not
CNC
Voltage
380v
Power(W)
3000w
Dimension(L*W*H)
1850x1680x1900
Weight
1850kg
Certification
CE and ISO
Warranty
12 month
After-sales Service Provided
Overseas third-party support available
Specifications
1. CNC vertical knee-type milling machine2. ISO and CE Certification
3. 12 step 35-1500r/min
XLK5030 Utmost precision Fanuc cnc knee style milling machene
The machine is suitable for machinery, light industry, instrument, motor, electrical appliance and moulds, and widely used in machining of plane and arbitrary angle plane, and slotting, drilling, reaming, boring etc.
Specification |
Unit |
XLK5030 |
Table size |
mm |
1370X300 |
Table Travel (X/Y/Z) |
mm |
820/300/400 |
Spindle nose to work surface |
mm |
35-435 |
Spindle hole taper |
--- |
7:24 ISO40 |
Rapid speed of table (X/Y/Z) |
mm/min |
4000/4000/3000 |
T-slots(No./Width/Pitch) |
mm |
3/14/80 |
Spindle speed range |
r/min |
1235-1500 |
Stroke of spindle quill |
mm |
70 |
Distance between spindle axis and column guideway |
mm |
285 |
Swivel angle of Vertical milling head |
--- |
±30° |
Main motor power |
kw |
3 |
Torque of X/Y/Z axis AC servo motor |
N.m |
7.7/7.7/15 |
Overall size |
mm |
1850X1680X1900 |
Net weight |
kg |
1850 |
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
1999
Factory Size
30,000-50,000 square meters
Total Employees
101 - 200 People
