XQ6332 Light Type Servo Drive Turret Ram-type Milling Machine

Name: XQ6332 Light Type Servo Drive Turret Ram-type Milling Machine
Brand: YOURONGXILI
SKU: 106421077
Availability: InStock

US$ 1,000 - 10,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

YOURONGXILI

Tengzhou Xili Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name YOURONGXILI

Model Number XQ6332

Type Universal

CNC or Not Normal

Voltage 380V

Power(W) 5000

Dimension(L*W*H) 1720*1680*2350

Weight 1680kg

Certification CE ISO

Warranty 12 MONTHS

After-sales Service Provided Engineers available to service machinery overseas

Specifications

Driven by servo motor
Table automatic feed on X,Y,Z
Automatic rapid feed X,Y,Z

XQ6332 light type servo drive turret ram-type milling machine

Specifications	Unit	XQ6332	XQ6332A		XQ6332B		XQ6332C
Table size	mm	1270X320	1370X320		1270*320		1370*320
Table travel (X/Y/Z)	mm	720/300/400	820/300/400		900/380/400		1000/380/400
Rapid speed of table (X/Y/Z)	mm/min	1000/1000/750
Spindle taper	---	3HP: R8 or ISO30; 5HP: ISO40
		IS040
Table feed (X/Y/Z)	mm/min	Variable
Distance between horizontal nose and table surface	mm	75-475
Distance between spindle axis and ram surface	mm	200
Spindle speed range	r/min	43-3225
		65-4660 (16 steps)
		12steps 35-1500
T-slots(No./width/pitch)	mm	3/14/80
Arm travel	mm	450
Main motor power	---	3HP or 5HP
		3Kw
Torque of X/Y/Z axis AC servo motor	N.m	10
Overall size	mm	1720×1680×2350		1820×1680×2350		1720×1680×2350		1820×1680×2350
Net weight	kg	1680		1730		1730		1780

Rotary table can be ordered at special request

Model	Table size	Max table travel - X/Y/Z	Max rotary angle of table	Distance between spindle center line and table surface
XQ6332W	1270*320	720/300/400	±45°	35-435
XQ6332AW	1370*320	820/300/400
XQ6332BW	1270*320	900/380/400
XQ6332CW	1370*320	1000/380/400
