Specifications
1. Driven by Ac servo motor2. Table automatic feed on X,Y,Z
3. Automatic rapid feed X,Y,Z
XL6230 CE certified Superior price performance ratio ram Milling Machine Cost
Specifications |
Unit |
XL6230 |
XL6230A |
XL6230B |
XL6230C |
|
Table size |
mm |
1270*300 |
1370*300 |
1270*300 |
1370*300 |
|
T-slots(NO./width/pitch) |
mm |
3*14*80 |
||||
Max table travel - X/Y/Z |
mm |
720/300/400 |
820/300/400 |
900/380/400 |
1000/380/400 |
|
Spindle taper |
- |
7:24 ISO40 |
||||
Distance between spindle nose and table surface |
mm |
100-500 |
||||
Spindle speed range |
r.p.m |
11 steps 45-1660 |
||||
Max swivel angle of milling head |
- |
360° |
||||
Table feed(X/Y/Z) |
mm/min |
No finite |
||||
Table rapid speed |
|
1000/1000/750 |
||||
Main motor power |
Kw |
2.2(V)/ 3(H) |
||||
Torque of X/Y/Z axis AC servo motor |
Nm |
10 |
||||
Overall size |
mm |
1730*1760*1700 |
1830*1760*1700 |
1730*1760*1700 |
1830*1760*1700 |
|
Rotary table can be ordered at special request
Model |
Table size |
Max table travel - X/Y/Z |
Max rotary angle of table |
Distance between spindle nose and table surface |
XL6230W |
1270*320 |
720/300/400 |
±45° |
60-460 |
XL6230AW |
1370*320 |
820/300/400 |
||
XL6230BW |
1270*320 |
900/380/400 |
||
XL6230CW |
1370*320 |
1000/380/400 |
