vertical bench drill press for metal machining

FOB Price

USD $3,000 - $5,000 / Set

1 Set(Min.Order)

Product Details

1. Get the ISO9001:2008 Certification
2. High rigidity, High accuracy, High efficiency, Flexibility

Square Column Vertical Drilling Machine Z5150B

Specification	Unit	Z5150B	Z5150B-1
Max drilling diameter	mm	50	50
Spindle taper		MT5	MT5
Spindle travel	mm	250	250
Spindle box travel(manual)	mm	200	200
Spindle speed steps		12	12
Spind feed steps		9	9
Spindle speed range	r.p.m	31.5~1400	31.5~1400
Table size spindle feed range	mm/r	0.056~1.80	0.056~1.80
Table size	mm	560 x 480	800 x 320
Longitudinal(cross)travel	mm	450/300	450/300
Vertical travel	mm	300	300
Max distance between spindle and table	mm	750	750
Main motor power	kw	3	3
Overall size	mm	1090x905x2465	1300x1200x2465
Net weight	kg	1250	1350

Suitable for machining medium and small size plates, discs, shells, complex work pieces, moulds etc. in batch production.

Tengzhou Xili Machine Tool Co., Ltd.: Contact nameCony Yang; Phone86-0632-5603977; AddressXingteng East Road, Tengzhou Economic Development Zone
