Help CenterX7130 Bed Milling Vertical Bed-type Milling Machine
Related Products
Vertical Bed-type Milling Machine X7130
1.Driven by Gear Power
2.Table automatic feed on X,Y,Z
3.Automatic rapid feed X,Y,Z
4.Optional power feed device
5.Motor: 5 kw
6.Easy control
7.Equipped with manual lubricating device, the lubrication on the lead screw and guideway
8.Cast iron with high precision, long service life
Specification of bed-type milling machine
Specification |
Unit |
X7130 |
|
Table size |
mm |
1370X300 |
1500X300 |
T-slots (No./width/pitch) |
mm |
3X16X63 |
|
Table Travel---X |
mm |
880 |
1000 |
Table Travel---Y |
mm |
510 |
|
Travel---Z |
mm |
450 |
|
Distance between spindle nose and table surface |
mm |
150-600 |
|
Rapid speed of table---Z |
mm/min |
1483 |
|
Spindle taper |
--- |
ISO40 |
|
Travel of spindle sleeve |
mm |
127 |
|
Spindle feed speed |
mm/rev |
0.04/0.08/0.15 |
|
Spindle speed range |
r/min |
43-3225(variable) |
|
|
r/min |
65-4660(16steps) |
|
Main motor |
HP |
5 |
|
Overall size |
mm |
1780X1460X2175 |
1900X1460X2175 |
Net weight |
kg |
1750 |
2100 |
CNC Type Bed-Type Milling Machine XK7130 also available
Picture of bed-type milling machine
Certificate of bed-type milling machine
Packaging and Shipping
Packaging : metal Milling machine covered with plywood case.
Shipping : 20 days after receiving the deposit
Company Information
It covers an area of 70000 square meters, with the building zone about 30000 square meters, including Tengzhou XILI Machine Tool Co.,Ltd. Shandong YOURONG Machine Tool Co.,Ltd. There are more than 800 workers with a technical center of provincial level.It is one of the biggest manufacturers of milling machines in south of Shandong Province.
The main products have developed to 7 series in recent years: CNC Planer-type machining center , CNC vertical machining center, CNC horizontal machining center series, CNC milling machine series, Knee-type milling machine series, planer-type milling machine , Single-face milling machine series,Vertical drilling machine series, Drilling and Milling machine series. We passed ISO9001 in 2002, and CE in 2007.
"Customers first, quality first" wich is the belief we always seek.
