Help CenterAutomatic 1.3M Single Side Hot Laminator
US$ 1,950 - 2,250
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Cold & Hot Laminator
Paper Size:
Other, 1270MM width
Brand Name:
Disen
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Other, Cold & Hot Laminator
Paper Size
Other, 1270MM width
Brand Name
Disen
Model Number
1300
Place of Origin
Guangdong, China
Technology parameters,Automatic 1.3M Single side hot laminator | |
| Max width (mm) | 1270mm |
| Max thickness (mm) | 23mm |
| Speed | 0-6m/min |
| Temp range | room temperature-120°C |
| Roller upgrade | Unilateral linkage to enhance |
| Roller heating | Infrared within the heating |
| Preheat time | 10-15min |
| Power consumption | 0.8-1kw/h |
| Fixed input power | 2200w |
| Fixed input volt | 110/220v |
| Net weight | 100kg |
| Dimensions | 680x1610x1140mm |
Machine configuration,hot cold laminator | ||
| 60wAdjustable deceleration torque motor | Under the roller diameter 110mm anti-mucosal silicone | Unilateral balanced regulator handwheel |
Anti-scratch stainless steel before working platform |
The finished map automatically rolling bodies | Non-contact infrared temperature measurement system |
| The upper roller diameter 130mm imports of high-temperature silicone | Wrinkle, anti-walk the ramp feeding mechanism (first) | To move the foot switch |
|
|
|
Product advantages,Automatic 1.3M Single side hot laminator
Reduce costs to improve quality,automatic hot roll laminator 1.5 yuan per square directly reduce costs · Color reproduction is good translucent high bubbles, snow point phenomenon Coated high efficiency, high yield Entire roll of 50 m coated not walk the ramp Can a single person or unattended operation 220 sq / hour · Thin adhesive will not wrinkle dark screen cover labor Can be used for low heating Lengbiao 50 ° C cold lamination can completely avoid air bubbles, snowflakes point phenomenon · The automatic Jiedi paper · Can be single or unattended operation 400 square feet / hour Scope of application,automatic hot roll laminator Wide coil coated for indoor photo outdoor car stickers Detailed description,Automatic 1.3M Single side hot laminator
1,Anti-walk the ramp feeding system can discharge covered the entire volume, and effective way to avoid screen deflection, greatly improve the efficiency of coated, lower labor costs.
2,Unilateral hand movements rubber roller linkage, manipulation of simple synchronized movements, uniform pressure.
3,The finished map automatic winding system, convenient, save labor, improve the yield.
4,Put materials from the bottom tearing paper hike tight system to improve the ductility of the film, and effective way to avoid fold.
5, Before and after the stainless steel work platform, scratch resistance, long life.
What are the advantages of thermal laminating machine,hot cold laminator
Heat laminating machine heat mounted membrane covered in a coating material by heating a new type of coating equipment, also known as heat-mounted machine. With the progress of the times, some of the old cold laminating process slowly heat-mounted replaced. But many people will be concerns about cold laminating and heat-mounted gap The effect of heat-mounted what will happen The traditional cold laminating machine is only a two roller machine, by pressure directly to the adhesive film is glued to the printed The machine is cheap, but relatively high cost of consumables. Laminating the effect is not good. This is also a major flaw. |
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2011
Factory Size
1,000-3,000 square meters
Total Employees
201 - 300 People
