12V 100W WATERPROOF LED POWER ADAPTER
specification | WT-A1 |
DC Output | 12V 8.33A |
Ripple&Noise | 120mVp-p |
line Regulation | ±5.0% |
load regulation | ±5.0% |
Efficiency | 85%Min |
AC input voltage range | 100-240V AC 50/60Hz |
AC inrush current | cold-start current 50A/240V(at 25°c) |
Over-load protection | 105%~135%hiccup mode,auto-recovery |
Over Voltage protection |
|
Over Current Protection | Auto Recovery |
hold up time | >5mS at full load 100Vac/47Hz;>10mS (at full load)110/220Vacc/50/60Hz |
Leakage Current | < 0.25mA at 220Vac/50Hz |
Insulation Resistance | 50VDC/≥50M |
Working Temp | -10°c~50°c |
safety standards | design refer to GB4943;UL60950;EN60950 |
MTBF | ≥50K at full load and 25°c |
IP | 67 |
size: 200*69*43mm
Products Details
• Place of origin:China
• MOQ : 100PCS ( you could first order samples from us to test the quality of our products)
• Price terms:F.O.B SZ
• payment terms: T/T in advance
• lead time: 10~15working days(up to your quantity orderd )
CERTIFICATION
50pcs/ctn
dimension:50*44*20.5CM3
1.MOQ:300PCS
2.Warranty:2 years
3.Delivery Time:15 days after we get your payment
4.Samples:You could order 1~3pcs samples to test,but it is not free.,it will take 3 working days to produce after we get your payment
5.Shipment:DHL,UPS,FedEx,Ocean,you could choose the most convenient one
6.Payment Term:T/T
