Wholesale Precision china supplier custom plastic Nylon screw m10 Nylon1010 screw
Material profile
MC Nylon (Natural/white)
MC Nylon,means Monomer Casting Nylon, is a kind of engineering plastics used in comprehensive industries, has been applied almost every industrial field.
The caprolactam monomer is first melted, and added catalyst, then poured it inside moulds at atmosphere pressure so as to shape in different castings, such as: rod, plate, tube. The molecule weight of MC Nylon can reach 70,000-100,000/mol, three times than PA6/PA66. Its mechanical properties are much higher than other nylon materials, such as: PA6/PA66. MC Nylon plays a more and more important role in the material list recommended by our country.
Since the end of 1980’s, Guangzhou Engineering Plastics Industireis Company has devoting herself on developing the technology of MC Nylon modification, greatly extended the applications in different industries. Basing on the MC Nylon, reinforced with variety of additives during the reaction, such as lubricant, molybdenum disulfide, graphite glass fiber, carbon fiber etc, to improve the properties, higher performance of wear-resistance, corrosion-resistance,
self-lubrication, vibration-absorption, noise-absorption. At the same time, as the technics and structure of the moulds is quite simple, so that it can be manufactured in lower cost, becomes the ideal substitutes of bronze, stainless steel, Babbitt alloy , PTFE and so on.
Oil Nylon (green)
Oil Nylon(green)is the new engineering plastics that developed by Guangzhou Engineering Plastics Industries Company in the later 1990’s by importing the advanced technology from UK, was the first authentic lubricating nylon that builds the liquid lubricant system during the processing stage, which makes its coefficient of friction is 50% lower than the general PA6 or PA66, the wear-resistance is 10 times than the general ones. Oil Nylon is specially developed for the parts of non-self-lubrication, heavy-loading and low-speed-running, which obviously resulted in a substantial increase in bearing life—5 times that of general PA6 and 25 times that of phosphor bronze! The lubricant contained within the material will not drain, adsorb or dry out and never needs replenishment. The uniform distribution of the lubricant throughout the product guarantees the constant performance of the parts over the whole service life and improvements in rate of wear, sliding frictional properties, abrasion resistance and stick slip performance, which are just a few of the benefits offered by this material. Oil Nylon has been successful in considerable enlarging the application of nylon in many industries and specifically for some un-lubricated running parts.
Other casting Nylon:
Oil Nylon + Carbon (Black)
Oil Nylon added carbon, has the very compact and crystal structure, which is better than the general casting nylon in the performance of high mechanical strength, wear-resistance, anti-aging, UV resistance and so on. It is suitable for making the bearing and other wear mechanical parts.
Oil MC901(Blue)
This improved MC Nylon, has striking blue color, which is better than general PA6/PA66 in the performance of toughness, flexibility, fatigue-resistance and so on. It is the perfect material of gear, gear bar, transmission gear and so on.
MC Nylon + MSO2(Light black)
MC Nylon added MSO2 can remain the impact-resistance and fatigue-resistance of casting nylon, as well as it can improve the loading capacity and wear-resistance. It has a wide application in making gear, bearing, planet gear, seal circle and so on.
Properties for your reference
plastic screw
Advantages
1.International leading technical supports,experienced professional engineer team
2.Quality assurance:ISO9001,SGS,RoHS,Testing Reports
3.ODM & OEM service,any size and shape is available
4.Various plastic material:uhmw-pe,nylon,pom,peek,pps,pei,pvc,teflon,pai,ect
5.Rich import and export experience
6.Outstanding performance:wear resistance,self lubricant,shock resistance,low temperature resistance,ect
Main characteristics
1. Very high-wear resistance, seven times wear resistance than steel, four times than PTFE
2. Very high anti-impact resistance, two times impact resistance than PC, five times than ABS.
3. Good self-lubrication, the same as PTFE, better than steel and brass appended lubricating oil.
4. Good anti-corrosion resistance, it has very stable chemicals property and can endure the corrosion of all kinds of corrosive medium and organic solvent in certain rang of temperature and humidity.
5. Very high-inadhesion resistance, the surface of product hardly affixes other material.
6. Very high-impact resistance, ten times impact resistance than PA66, eight times than PTFE.
7. Good low temperature resistance, in liquefied nitrogen (- 196℃), it still has the prolongation.few other materials can reach to this performance.
8. Non-toxic and clean property, UHMW-PE, which is the material that Food and Drug Administration (FDA) and United States Department of Agriculture (ASDA) permit to apply in food and medicine fields.
Applications
- Paper making industry: with its performance of high wear resistance and good self-lubrication, can be used in: vacuum box panel, dehydration plank, drawknife, pressurize assembly, shaft sleeve of paper-cutting machine and so on. The thickness of UHMW-PE tube below 10mm, can be made into covering tube of strap transport and transcribing machine roller.
- Food and beverage light industry: with its performance of high wear resistance, anti-impact resistance, inadhesion resistance, non-toxic and clean property, can be manufactured: moving plate, transport screw, gear and so on, which is easy-cleaning, long-enduring, and anti-mildew,and be used in other clear parts.
- Waste-water industry:Polluting mud,scraping plate of helix transport,slurry pump impeller,pump bearing bush,grit collection system,defecator gear,precipitation pool scaleboard and so on
- Electronic Industry: Surface dealing of semiconductor process, air-pollution control system, waste-water vent control and so on. UHMW-PE, has the excellent Performance of low-temperature resistance, which has a good ductibility in the Liquefied helium (-269℃), was started to apply in the refrigeration technology and low-temperature field. The latest UHMW-PE tube can be applied in semiconductor field instead of a great deal of PTFE tubes.
- Textile industry: With its performance of high-wear resistance, anti-impact and good self-lubrication, the products, such as: strap knot, gear, cushion baffle, bearing bush and so on.
- Sport and amusement industry: ski tools lining, assembly of track vehicle in ice and snow, earth plate of glider plane, assembly of steel ball equipment, shaft sleeve of all size, rolling ball path, accessory of mechanization sledge and so.
- Medical industry: Body embedded substance, artificial joints, rectifying surgical machine and bracket, orientation rack of surgical machine.
Chemical and other industry: galvanization hardware, agricultural machine, shipping parts, mechanical parts of low-temperature atomic energy and so on.Mostly using of its high-wear resistance, high anti-impact resistance, anti-cold resistance, self-lubrication, electric characteristic.
Why choose us?
1.Rich industry experience since 1988.
2.Wide arrange product line, including plastics sheet/rod/parts/accessories: MC NYLON, OIL NYLON, POM, UHMW-PE, PU, PETP, PC, PTFE, PVDF, PPS, PEEK, PAI, PI, PBI ect.
3.Manufacture,design and processing service as per your demand.
4.Professional R&D team,welcome to ODM & OEM
5.Professional after sale team
Purchase order flow
1.Inquiry or send your drawing to us
2.Quotation
3.Confirm order detail
4.Produce sample
5.Confirm sample
6.Produce mass item
7.Deliver items
8.After sale service
FAQ
Q1:What's your main product?
A1:Our main product is sheet,rod,tube and parts.Our advantage is ODM & OEM.Any shape and size is available.
Q2:What material is available?
A2:All engineering plastic is available,for example uhmwpe,nylon,derlin,peek,polyurethane,acrylic,pai,pei,ect.Even we can partial metal part,e.g bearing,roll,tube and so on.
Q3:What department do you have?
A3:We have cnc machined centre,molding department,packing department,raw material warehouse,QC,ect.The part can be machined and molded.
Q4:Do you have warranty period?
A4:Yes,we have.The warranty time is three month.
