Plastic and Double Screw Rubber Extruder Machine Price

Name: Plastic and Double Screw Rubber Extruder Machine Price
Brand: Doubleelephants
SKU: 106359147
Availability: InStock

US$ 5,000 - 50,000 MOQ: 1 Set

Key Specifications

Screw Design:

Double-screw

Automatic Grade:

HIGH LEVEL

Place of Origin:

China

Shanghai Double Elephant Rubber & Plastic Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Screw Design Double-screw

Automatic Grade HIGH LEVEL

Place of Origin China

Brand Name Doubleelephants

Model Number XJW -SEIRES

Voltage 380V/50Hz

Power(W) Lower

Weight 3 T -10 T

Certification ISO CE certificate

After-sales Service Provided Engineers available to service machinery overseas

rubber extruder machine,double screw rubber extruder machine, double screw rubber extruder machine price

Rubber extruder Detail specifications:

Model	XJW-90	XJW-100	XJW-120	XJW-150	XJW-200	XJW-250
screw diameter	Φ90	Φ100	Φ120	Φ150	Φ200	Φ250
screw length-diameter raito	1:12	1:12	1:12	1:12	1:12	1:12
screw type	such as deep not equi distance
screw speed	10-50	10-50	10-45	10-40	10-35	10-30
main motor eletrical power(KW)	45	55	75	90	200	320
main motor speed(r/min)	980	980	980	980	980	980
pressure vapor(mpa)	0.3-0.5	0.3-0.5	0.3-0.5	0.3-0.5	0.3-0.5	980
cooling water pressure(mpa)	0.3	0.3	0.3	0.3	0.3	0.3
cooling water temperature(℃)	0-18	0-18	0-18	0-18	0-18	0-18
production capacity(kg)	150-250	200-350	300-500	500-800	800-1500	1500-2000
weight equipment(kg)	3000	3500	4500	5500	9000	10000
size: length * width * high(mm)	260017001650	300018001650	330018001650	360018001650	450019001650	550020001650
