Home > Products > PCB & PCB Assembly > GPS PCBA Module, GPS PCBA Accessories, GPS PCBA Kits
GPS PCBA Module, GPS PCBA Accessories, GPS PCBA Kits
- 30000 Piece / Pieces per Month
- Shenzhen.Hongkong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
1 layer pcb assembly, single layer pcba, 254000 USD trade assurance
-
pcba factory ISO certificate/ pcba factory China/ pcba OEM
-
EMS PCB PCBA, EMS service, EMS supplier
-
electronic assemby, electronic manufacturing, electronic oem
-
single layer pcba, 1 layer pcb assembly, single layer pcb assembly
-
clone pcb pcba copy service electronics copy
Product Details
| Place of Origin | Guangdong, China | Brand Name | MOKO | |
| Model Number | MK50630BC | Base Material | FR4, ALU, PI, CEM | |
| Copper Thickness | 0.5OZ to 5OZ | Board Thickness | 1.6mm, 1.0/ 2.0 mm | |
| Min. Hole Size | 0.25mm | Min. Line Width | 0.075mm | |
| Min. Line Spacing | 0.075mm | Surface Finishing | HASL, OSP, ENIG |
Anti-static package with high quality carton box
Product Description
GPS PCBA Module, GPS PCBA Accessories, GPS PCBA Kits
MOKO services:
- Contract Manufacturing
- Engineering Services
- PCB Fabrication
- Component sourcing
- PCB assembly
- Function test (for free)
- Plastics and Molds
MOKO advantages:
- ISO9001: 2008 certificates
- UL and ROHS certificates
- PCBA free function test
- PCBA with 2 years warranty
- 10 years producing experience
- 8 SMT lines and 4 Thru-hole lines
- 400 workers
Orientronic PCB assembly Equipment:
- SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
- Reflow Oven: FolunGwin FL-RX860
- Wave Soldering Machine: FolunGwin ADS300
- Automated Optical Inspection (AOI): Aleader ALD-H-350B
- Fully Automatic SMT Stencil Printer: FolunGwin Win-5
Technical Support:
- Professional Surface-mounting and Through-hole soldering Technology
- Various sizes like 1206,0805,0603 components SMT technology
- ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
- PCB Board Assembly With UL,CE,FCC,Rohs Approval
- Nitrogen gas reflow soldering technology for SMT.
- High Standard SMT&Solder Assembly Line
- High density interconnected board placement technology capacity.
PCB Capacities and Technical Specification
| Order Quantity | 1-500,000 |
| Layer | 1,2,4,6,upto 18 layer |
| Material | FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc |
| PCB type | Rigid,flexible,rigid-flexible |
| Shape | Any shape: Rectangular,round,slots,cutouts,complex,irregular |
| Max PCB dimensions | 20inch*20inch or 500mm*500mm |
| Thickness | 0.2~4.0mm, Flex 0.01~0.25'' |
| Thickness tolerance | ± 10% |
| Copper thickness | 0.5-4 oz |
| Copper thickness tolerance | ± 0.25oz |
| Surface finish | HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc |
| Solder mask | Green, red,white,yellow,blue,black, Double-sided |
| Silk screen | White,yellow,black,or negative, Double-sided or single-sided |
| Silk screen min line width | 0.006'' or 0.15mm |
| Min drill hole diameter | 0.01'',0.25mm.or 10 mil |
| Min trace/gap | 0.075mm or 3mil |
| PCB cutting | Shear,V-score,tab-routed |
PCBA Capabilities
| Turnkey PCBA | PCB+components sourcing+assembly+package |
| Assembly details | SMT and Thru-hole, ISO SMT and DIP lines |
| Lead Time | Prototype: 15 work days. Mass order: 20~25 work days |
| Testing on products | Flying Probe Test, X-ray Inspection, AOI Test, Functional test |
| Quantity | Min quantity: 1pcs. Prototype, small order, mass order, all OK |
| Files needed | PCB: Gerber files(CAM, PCB, PCBDOC) |
| Components: Bill of Materials(BOM list) | |
| Assembly: Pick-N-Place file | |
| PCB Panel Size | Min size: 0.25*0.25 inches(6*6mm) |
| Max size: 20*20 inches(500*500mm) | |
| PCB Solder Type | Water Soluble Solder Paste, RoHS lead free |
| Components details | Passive Down to 0201 size |
| BGA and VFBGA | |
| Leadless Chip Carriers/CSP | |
| Double-sided SMT Assembly | |
| Fine Pitch to 0.8mils | |
| BGA Repair and Reball | |
| Part Removal and Replacement | |
| Component package | Cut Tape,Tube,Reels,Loose Parts |
| PCB assembly process | Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing |
MOKO Made Products:
Certificates:
Company Profile
MOKO TECHNOLOGY LTD is an expert at PCB and PCBA manufacture, based in Shenzhen, Guangdong, China. We are specialized in manufacturing Single-Sided Boards, Double-Sided Boards and multilayer PCB. We are honored as the excellent supplier of many companies all around this world. We can offer all kinds of services including PCB and PCB assembly sample orders and batch orders. We have got the ISO9001:2000, ISO14001, and UL RoHS certifications. Now our PCB daily capacity reaches 1000 square meters, and PCB assembly can reach 100,000,000 units per month. We deeply believe that our good service and experience will completely meet you need. Integrity, value and innovation are the forces that drive our success. We are the smart choice for you and the trusted source at the center of your deal. Welcome the win-win situation together.
Contact Us
- Shenzhen Moko Technology Ltd.
- Contact nameRosina Zeng Chat Now
- Phone86-755-23573370
- Address#401,U2,BLDG2,Guanghui Tech park Minqing Rd Longhua , Shenzhen, Guangdong
