Help CenterQuick Turn 2 Layer Rohs Fr4 Led Pcb
US$ 0.1 - 8
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MOKO
Model Number:
MKPCB01H
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen.Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Led Tube Light AssemblyUS$ 0.58 - 8.58MOQ: 100 Pieces -
Led Traffic Light PcbUS$ 0.58 - 8.58MOQ: 100 Pieces
-
Shenzhen Factory Produce Led PcbaUS$ 0.12 - 1MOQ: 1 Piece
-
Professional Led Pcb Assembly Service 2 Years WarrantyUS$ 0.12 - 1MOQ: 1 Piece
-
Factory Produce OEM Led Products Aluminum PCB LEDUS$ 0.1 - 1MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
MOKO
Model Number
MKPCB01H
Base Material
FR4
Copper Thickness
1oz
Board Thickness
1.6mm
Min. Hole Size
0.1mm
Min. Line Width
0.1mm
Min. Line Spacing
0.1mm
Surface Finishing
HASL
Quick turn 2 layer rohs fr4 led pcb
Services:
- Contract Manufacturing
- Engineering Services
- PCB Design & Assembly
- Component Sourcing
- Product Design
- Prototyping
- Cable and Wire Assemblies
- Plastics and Molds
Factory Ability:
- § Professional surface-mounting and through-hole soldering technology
- § Various sizes like 1206, 0805, 0603 components SMT technology
- § ICT (In Circuit Test), FCT (Functional Circuit Test) technology
- § PCB assembly with UL, CE, FCC, RoHS approval
- § Nitrogen gas reflow soldering technology for SMT
- § High standard SMT and solder assembly line
- § High density interconnected board placement technology capacity
Function and Specification:
| 1 | Layers | Single Sided,2 to 18 Layer |
| 2 | Board material type | FR4,CEM-1,CEM-3,ceramic substrate board, aluminum based board, high-Tg, Rogers and more |
| 3 | Compound material lamination | 4 to 6 layers |
| 4 | Maximum dimension | 610 x 1,100mm |
| 5 | Dimension tolerance | ±0.13mm |
| 6 | Board thickness coverage | 0.2 to 6.00mm |
| 7 | Board thickness tolerance | ±10% |
| 8 | DK thickness | 0.076 to 6.00mm |
| 9 | Minimum line width | 0.10mm |
| 10 | Minimum line space | 0.10mm |
| 11 | Outer layer copper thickness | 8.75 to 175µm |
| 12 | Inner layer copper thickness | 17.5 to 175µm |
| 13 | Drilling hole diameter (mechanical drill) | 0.25 to 6.00mm |
| 14 | Finished hole diameter (mechanical drill) | 0.20 to 6.00mm |
| 15 | Hole diameter tolerance (mechanical drill) | 0.05mm |
| 16 | Hole position tolerance (mechanical drill) | 0.075mm |
| 17 | Laser drill hole size | 0.10mm |
| 18 | Board thickness and hole diameter ratio | 10:1 |
| 19 | Solder mask type | Green, Yellow, Black, Purple, Blue, White and Red |
| 20 | Minimum solder mask | Ø0.10mm |
| 21 | Minimum size of solder mask separation ring | 0.05mm |
| 22 | Solder mask oil plug hole diameter | 0.25 to 0.60mm |
| 23 | Impedance control tolerance | ±10% |
| 24 | Surface finish | Hot air level, ENIG, immersion silver, gold plating, immersion tin and gold finger |
Products and Factory Pictures:
