Precision panel saw for MDF board cutting.
Dimension of sliding table |
3800x 375mm |
Gross cut capacity |
3800mm |
Width of cut between saw blade and rip fence |
1250mm |
Saw blade diameter |
300mm(250- 400mm) |
Height of cut (300mm) |
80mm |
Speed of main saw spindle |
4500/6000rpm |
Main spindle diameter |
30mm |
Tilting saw blade |
0-45° |
Main motor |
220v/380v/415v, 5.5kw |
Scoring saw blade diameter |
120mm |
Speed of scoring saw blade |
8000rpm |
Scoring saw diameter |
20mm |
Scoring motor |
0.75kw |
Gross weight |
950kg |
Packing size of machine body(L*W*H) |
2200*1150*1100mm |
packing size of sliding table(L*W*H) |
3950*480*320mm |
Operate Manual
Voltage change
Whole life after-sale service
Why have to buy a panel saw?
It is professional cutting saw for MDF board.
How to choose, it has so many models!
Just tell us your Max. board length going to cut, We choose for you.
Does this saw can cut aluminum? And how many thickness?
It can cut aluminum, thickness under 5mm.
Can it use to cut acrylic panel?
Yes totally no problem. It is use to cut acrylic panel.
MOQ? Quality?
1 set , Feedback very good! Produced in big factory.
