Specifications
flexible pcb1.Competitive price,Good sale-service
2.High quality pcbs
3.Experienced staff
4.China pcb factory
Welcome to MOKO!
Our PCB board manufacture and PCB Assembly service
* PCB board file with parts list provided by customers
* PCB board made, circuit board parts purchased by us
* PCB board with parts assembled
* Electronic testing circuit board or PCBA
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
* One stop service for PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
flexible pcb
Your trust sources for pcb and pcba service,send us your gerber file and we will return your our best quotation!
*Specification of flexible pcb
1.Number of layer: 1 to 2 layers (flexible)
2.Base material thickness: 25, 50, 75, 100um, 1/2, 1, 2, 3mil
3.Copper conductor thickness: 18, 35, 70um, 1/2, 1, 2oz
4.Materials: polyester, polyimide
5.Copper: RA, ED
6.Minimum hole diameter: 0.2mm
7.Minimum line/space width: 0.1mm
8.Minimum annular ring: 0.1mm
9.Maximum panel size: 400 x 400mm
10.Plating: solder, nickel, gold
11.Volume resistivity: 1 x 1,015 (IPC-TM-650 2.5.6.17)
12.Dissipation factor (1MHz): 0.04 (mil-P55617)
13.Solder heat resistance: 300-degree C/10 seconds
14.Dielectric strength: 5kV (IPC-TM-650 2.5.6.1)
15.nsulation resistance: 1,000mW (IPC-TM-650: 2, 6, 3, 2 at ambient)
Peeling strength (180-degree direction): 1.0kg/cm (IPC-TM-650 2.4.9)
Flammability: 94 V-0 (UL94)
Surface resistance: 5 x 1,012 (IPC-TM-650 2.5.6.17)
Dissipation factor (1MHz): 0.04 (mil-P-55617)
RoHS compliant
View Of Our Factory:
