Shenzhen Yamaha SMT lines PCBA PCB assembly

Name: Shenzhen Yamaha SMT lines PCBA PCB assembly
Brand: Moko
Price: USD $0.24 - 100 / Piece

FOB Price

USD $0.24 - $100 / Piece

100 Pieces(Min.Order)

Supply Ability 1000 Square Meter / Square Meters per Month
Port ShenZhen HongKong
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	Moko	Model Number:	MKPCBAPP0393
Base Material:	FR4,Alu.	Copper Thickness:	1 oz	Board Thickness:	1.6mm
Min. Hole Size:	0.25mm	Min. Line Width:	0.075mm	Min. Line Spacing:	0.075mm
Surface Finishing:	HASL,ENIG

Packaging Details

Inner packing: Vaccum packing/Plastic bag
Outer packing: Standard carton packing

Product Description

Specifications

Yamaha SMT lines,RoHS,UL
Double sided SMT,wave soldering
AOI,X-ray test
20-25 days lead time
L/C,T/T,Western Union,PayPal

Welcome to Moko

-----over 10 years professional PCB&PCBA Manufacturer

Moko, your single point of contact for all of your raw materials, parts, and PCB assembly, also offers:

- Contract Manufacturing
- Engineering Services
- PCB Design & Assembly
- Product Design
- Prototyping
- Cable and Wire Assemblies
- Plastics and Molds

PCB Technical Specification

Layer	1,2,4 or 6,upto 18 layer
Material	FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2
Order Quantity	1-500,000
Board shape	Rectangular,round,slots,cutouts,complex,irregular
Board type	Rigid,flexible,rigid-flexible
Board material	FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc
Board cutting	Shear,V-score,tab-routed
Board thickness	0.2~4.0mm,Flex 0.01~0.25''
Copper weight	0.5-4 oz
Solder mask	Double-sided green LPI,Also support red,white,yellow,blue,black
Silk screen	Double-sided or single-sided in white,yellow,black,or negative
Silk screen min line width	0.006'' or 0.15mm
Max board dimensions	20inch20inch or 500mm500mm
Min drill hole diameter	0.01'',0.25mm.or 10 mils
Surface finish	HASL,Nickle,Imm Gold,Imm Tin,Imm Silver,OSP etc
Board thickness tolerance	± 10%
Copper weight tolerance	± 0.25oz
Minimal slot width	0.12'',3.0mm,or 120mils
V-score depth	20-25% of board thickness
Plated through holes	Yes
Sink holes	Yes
Design file format	Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG

PCB Lead Time

	Single,Double sided	Four layer	Six layer	Above eight layer	HDI
Sample lead time(Normal)	5-6	6-7	7-8	10-12	15-20
Sample lead time(Fastest)	48 to 72 hours	5	6	6-7	12
Mass production lead time(First batch)	7-9	10-12	13-15	16	20

PCB Assembly Capabilities

Quantity	Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000
Type of Assembly	SMT,Thru-hole
Solder Type	Water Soluble Solder Paste,Leaded and Lead-Free
Components	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Bare Board Size	Smallest:0.250.25 inches Largest:2020 inches
File Formate	Bill of Materials Gerber files Pick-N-Place file
Types of Service	Turn-key,partial turn-key or consignment
Component packaging	Cut Tape,Tube,Reels,Loose Parts
Turn Time	Same day service to 15 days service
Testing	Flying Probe Test,X-ray Inspection AOI Test
PCB assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Detailed Terms for PCB Assembly

Technical requirement for PCB&PCB assembly:
---- Professional Surface-mounting and Through-hole soldering Technology
---- Various sizes like 1206,0805,0603 components SMT technology
---- ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
---- PCB Assembly With UL,CE,FCC,Rohs Approval
---- Nitrogen gas reflow soldering technology for SMT.
---- High Standard SMT&Solder Assembly Line
---- High density interconnected board placement technology capacity.

Quote requirement for PCB&PCB assembly:
---- Gerber file and Bom list
---- Clear pics of PCBA or PCBA sample for us
---- Test method for PCBA

Moko PCB Assembly Show

Moko Factory Overview

Contact with us:

Company Profile

Shenzhen Moko Technology Ltd.

MOKO TECHNOLOGY LTD is an expert at PCB and PCBA manufacture, based in Shenzhen, Guangdong, China. We are specialized in manufacturing Single-Sided Boards, Double-Sided Boards and multilayer PCB.

We are honored as the excellent supplier of many companies all around this world. We can offer all kinds of services including PCB and PCB assembly sample orders and batch orders.

We have got the ISO9001:2000, ISO14001, and UL RoHS certifications. Now our PCB daily capacity reaches 1000 square meters, and PCB assembly can reach 100,000,000 units per month.

We deeply believe that our good service and experience will completely meet you need. Integrity, value and innovation are the forces that drive our success. We are the smart choice for you and the trusted source at the center of your deal. Welcome the win-win situation together.

Contact Us

Shenzhen Moko Technology Ltd.: Contact nameRosina Zeng; Phone86-755-23573370; Address#401,U2,BLDG2,Guanghui Tech park Minqing Rd Longhua Shenzhen,Guangdong
