BPC Electrical Instrument Enclosures

BPC Electrical Instrument Enclosures thumbnail-1
BPC Electrical Instrument Enclosures photo-1
US$ 717 - 2,822 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
KAIWEI
Model Number:
BPC6080400304
Contact Supplier Request Quote Chat Now
Shanghai Kaiwei Electric Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name KAIWEI
Model Number BPC6080400304
Protection Level IP54
Type Network Cabinet
External Size 600mm*800mm*400mm

Specifications

BPC electrical instrument enclosures
1.Nine-fold section by means of whole welding ensures high strength
2.IP54


Product Description



BPC electrical instrument enclosures

1. Material:  SUS304(Other material can be optional)

2. Surface Treatment:  Wire Drawing

3. Class of Protection: IP54(According to GB4205-1993)



Item Name:
Material: SUS304(Other material can be optional)
Thickness: Frame:9-fold Sections 1.5mm Door Plate:2.0mm   Laminated Plate:2.0mm
Standard Configuration: Cabinet Body,Back Plate,Front Upper Glass Door,Front Lower Steel Door,Keyboard Drawer,Sealing Strip,Laminated Plate,Door Lock and Casters(Optional)
Surface Treatment: Wire Drawing
Class of Protection: IP54(According to GB4205-1993)
MOQ: 100 PCS
Supply Ability: 10000 PCS/Month
Delivery Time: 10-15 days
Remark: Special Demands Can Be Customized






No.
Order No.
Width
Height
Depth
1 BPC6080400304 600 800 400
2 BPC6080500304 600 800 500
3 BPC6080600304 600 800 600
4 BPC6010500304 600 1000 500
5 BPC6010600304 600 1000 600
6 BPC6010700304 600 1000 700
7 BPC6010800304 600 1000 800
8 BPC6012600304 600 1200 600
9 BPC6012700304 600 1200 700
10 BPC6012800304 600 1200 800
11 BPC8012600304 800 1200 600
12 BPC6014600304 600 1400 600
13 BPC6014700304 600 1400 700
14 BPC6014800304 600 1400 800
15 BPC8014600304 800 1400 600
16 BPC6016600304 600 1600 600
17 BPC6016800304 600 1600 800
18 BPC8016600304 800 1600 600
19 BPC8016800304 800 1600 800
20 BPC6018600304 600 1800 600
21 BPC6018800304 600 1800 800
22 BPC8018600304 800 1800 600
23 BPC8018800304 800 1800 800
24 BPC6020600304 600 2000 600
25 BPC6020800304 600 2000 800
26 BPC8020600304 800 2000 600
27 BPC8020800304 800 2000 800
28 BPC6022600304 600 2200 600
29 BPC6022800304 600 2200 800
30 BPC8022600304 800 2200 600
31 BPC8022800304 800 2200 800





Details:



Main advantage of BPC electrical instrument enclosures :

  1. Full-wire drawing surface and delicate stainless steel accessories show luxury character of the cabinet body.
  2. Humanized design of keyboard and mouse system and the internal installation space is flexible and convenient.
  3. Cabinet body made of nine-fold section by means of whole welding not only ensures high strength but also make the protection class of the cabinet body reach to IP54,thus having protection capability in severe environments.
  4. Surveillance area is equipped with non-reflect safety glass to ensure safety and reliability.
  5. Optional high performance caster system can guarantee mobility of the cabinet body on the site.
