Outdoor Sanken inverter cabinet

Specifications

outdoor fuji frequency conversion cabinet IP56
1.The mounting plate is made of galvanized plate

Outdoor Sanken inverter cabinet

1. Material: Cold Rolled Steel Sheet or Stainless Steel SUS304

2. Surface Treatment: Etch Primer for Box Body and Door Plate,Powder Coating for Outside,Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized.

3. Class of Protection: IP56(According to GB4205-1993)   PU Foaming Sealing



Item Name:		Outdoor Sanken inverter cabinet
Material:		Cold Rolled Steel Sheet or Stainless Steel
Thickness:		Cabinet Body 2.0mm Door Plate:2.5mm Mounting Plate:2.5mm
Standard Configuration:		Door Plate,Cabinet Body,Sealing Strip,Grouding Sets,Mounting Plate,Door Lock
Surface Treatment:		Etch Primer for Cabinet Body and Door Plate,Powder Coating for Outside,Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized.
Class of Protection:		IP56(According to GB4205-1993)
MOQ:		100 PCS
Supply Ability:		10000 PCS/Month
Delivery Time:		10-15 days
Remark:		Special Demands Can Be Customized





Main advantage of Outdoor Sanken inverter cabinet :

1. The door plate and box body are installed with special screws and retainers in accordance with common standards, which can ensure the protection class and the operation and maintenance in the narrow space in the box.
2. Multiple protection grooves are designed at the box opening can not only reinforce the structure but also prevent the entry of dirt or water when the door is opening.
3. PU foaming sealing strip ensures a protection class of IP56 to box body.
4. The grounding line can be connected to the box body and door plate.
5. Racks with screw holes are provided on both sides of the box to ensure the max mounting height and ensure the installation of supporting rail or mounting plate.
6. The special plastic insulating sleeve can provide sealing and prevent door plate screw loosening, and guide screws when they are tightened.
