Hot Sell 125Khz or 13.56Mhz laundry plastic tag

Specifications

Hot Sell 125Khz or 13.56Mhz laundry plastic tag
Customized LOGO and artwork Design
Rewritable and large User memory

Hot Sell 125Khz or 13.56Mhz laundry plastic tag

The laundry tag is design especially for this circumstance; it's an RFID products encapsulated by nylon fiber with twice Injection. Firstly, we made a RF transponder in special size by COB and copper coil, by high temperature glue, solidified in roaster about 200 Celsius degree. After place the RF transponder in the base housing done in first injection, by over mold the nylon is injected second time and envelope the RF parts and base housing together, integrate to be a finished laundry tag. It is looks like a real button or nail, with to tiny hole which is easy to be sewed, and could be any color as request.

RFID Laundry tags are specially designed for harsh environment, such as laundry management, industrial chain, car tire etc. They can be easily applied into non-mental environment. The special UHF laundry tags are soft and flexible. They can be Sewn on clothes.





Applications



Specifications



Diameter	10 / 14 / 15.5 / 17 / 22mm
Thickness	2 / 2.8 / 3 / 3 / 3mm
Working Frequency	125 KHz / 13.56 MHz
Reading Range	Depending on the reader design
Material	PA9T
Operating Temperature	-25 to 200°C
Storage Temperature	-25 to 200°C
	160°C for 50hrs
	220°C for 30secs
Assembly	Injection Moulding
Approx. Weight	0.2 / 0.8 / 1 / 1 / 1.6g
Protection Class	IP68
Standard Color	Black
Packaging	1000pcs
