BAK Electrical Panel Box Sizes

Name: BAK Electrical Panel Box Sizes
Brand: KAIWEI
SKU: 106339317
Availability: InStock

US$ 770 - 1,330 MOQ: 100 Sets

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

KAIWEI

Model Number:

BAK6014400304

Shanghai Kaiwei Electric Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name KAIWEI

Model Number BAK6014400304

Protection Level IP55

Type Control Box

External Size 600mm*1400mm*400mm

Specifications

1.Optional lifting ring system ensures easy transporting
2.PU foaming sealing strip ensures a protection class IP56

BAK electrical panel box sizes

1. Material: SUS304(Other material can be optional)

2. Surface Treatment: Wire Drawing,Mounting Plate is Galvanized

3. Class of Protection: IP56(According to GB4205-1993) PU Foaming Sealing

Item Name:		BAK electrical panel box sizes
Material:		SUS304(Other material can be optional)
Thickness:		Box Body:1.5mm(2.0mm optional) Door Plate:2.0mm Mounting Plate:2.5(3.0mm optional)

Standard Configuration:		Box Body,Door Plate,Sealing Strip,Grounding Sets,Mounting Plate,Door Lock

Surface Treatment:		Wire Drawing,Mounting Plate is Galvanized


Class of Protection:		IP56(According to GB4205-1993) PU Foaming Sealing

MOQ:		100 PCS
Supply Ability:		10000 PCS/Month
Delivery Time:		10-15 days
Remark:		Special Demands Can Be Customized

Details:

Main advantage of BAK electrical panel box sizes:

PU foaming sealing strip ensures a protection class of IP56 to box body.
Widened box frame, bearing hinge and door plate square tube stiffener ensures high strength of the box body.
Optional 3.0mm galvanized mounting plate and high-strength mounting rack ensures the reliability of the mounting parts (can be used for wiring outside the box).
Bottom inlet/outlet line device ensures easy installation of inlet/outlet lines.
Optional lifting ring system ensures easy transporting.
Surface wire drawing treatment (sand blasting is available in high-class box).
