AK Luxury Vertical Electrical Waterproof Metal Control Box
Specifications
AK luxury vertical electrical waterproof metal control box1.Optional lifting ring system ensures easy transporting
2.IP 56
AK luxury vertical electrical waterproof metal control box
1. Material: Cold Rolled Steel Sheet
2. Surface Treatment: Etch Primer for Box Body and Door Plate,Powder Coating for Outside,Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized.
3. Class of Protection: IP56(According to GB4205-1993) PU Foaming Sealing
| Item Name: | AK luxury vertical electrical waterproof metal control box | |||||||
| Material: | Cold Rolled Steel Sheet | |||||||
| Thickness: | Box Body:1.5mm(optional 2.0mm) Door Plate:2.0mm Mounting Plate:Standard 2.5mm(optional 3.0mm) | |||||||
| Standard Configuration: | Box Body,Door Plate,Sealing Strip,Grounding Sets,Mounting Plate,Door Lock,Lifting Ring(optional) | |||||||
| Surface Treatment: | Etch Primer for Box Body and Door Plate,Powder Coating for Outside,Texture Optional as RAL7032 or RAL7035,Mounting Plate is galvanized. | |||||||
| Class of Protection: | IP56(According to GB4205-1993) PU Foaming Sealing | |||||||
| MOQ: | 100 PCS | |||||||
| Supply Ability: | 10000 PCS/Month | |||||||
| Delivery Time: | 10-15 days | |||||||
| Remark: | Special Demands Can Be Customized | |||||||
|
No. |
Order No.(RAL7032) |
Order No.(RAL7035) |
Width |
Height |
Depth |
| 1 | AK601440002 | AK601440005 | 600 | 1400 | 400 |
| 2 | AK801440002 | AK801440005 | 800 | 1400 | 400 |
| 3 | AK121440002 | AK121440005 | 1200 | 1400 | 400 |
Details:
Main advantage of AK luxury vertical electrical waterproof metal control box :
- PU foaming sealing strip ensures a protection class of IP56 to box body.
- Widened box frame, bearing hinge and door plate square tube stiffener ensures high strength of the box body.
- Optional 3.0mm galvanized mounting plate and high-strength mounting rack ensures the reliability of the mounting parts (can be used for wiring outside the box).
- Bottom inlet/outlet line device ensures easy installation of inlet/outlet lines.
- Optional lifting ring system ensures easy transporting.
Equipment:
Office:
Certificates:
...
