BAE Waterproof Electrical Floor Box

Name: BAE Waterproof Electrical Floor Box
Brand: KAIWEI
SKU: 106339167
Availability: InStock

US$ 400 - 919 MOQ: 100 Sets

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

KAIWEI

Model Number:

BAE6080250304

Shanghai Kaiwei Electric Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name KAIWEI

Model Number BAE6080250304

Protection Level IP55

Type Control Box

External Size 600mm*800mm*250mm

Specifications

1.Multiple Protection grooves can prevent the entry of dirt or water
2.PU foaming sealing strip ensures a protection class IP56

BAE waterproof electrical floor box

1. Material: SUS304(Other material can be optional)

2. Surface Treatment: Wire Drawing,Mounting Plate is Galvanized

3. Class of Protection: IP56(According to GB4205-1993) PU Foaming Sealing

Item Name:		BAE waterproof electrical floor box
Material:		SUS304(Other material can be optional)
Thickness:		Box Body:1.5mm Door Plate:2.0mm Mounting Plate:2.5mm

Standard Configuration:		Box Body,Door Plate,Sealing Strip,Grounding Sets,Mounting Plate,Door Lock

Surface Treatment:		Wire Drawing,Mounting Plate is Galvanized


Class of Protection:		IP56(According to GB4205-1993) PU Foaming Sealing

MOQ:		100 PCS
Supply Ability:		10000 PCS/Month
Delivery Time:		10-15 days
Remark:		Special Demands Can Be Customized

Details:

Main advantage of BAE waterproof electrical floor box:

PU foaming sealing strip ensures a protection class of IP56 to box body.
Galvanized mounting plate can also be used for wiring outside the box.
Multiple Protection grooves are designed at the box opening for reinforcement, which can prevent the entry of dirt or water when the door is opened.
Special SUS304 stainless steel lock system with double-teeth cylinder shows high quality and ensures universality.
Surface wire drawing treatment (sand blasting is available in high-class box).
Mounting plate and supporting rack with flanges on both sides ensures the max mounting strength.
