Rectangle heavy-duty industrial connector is designed in accordance with DIN/EN61984 standard. Its performance test is compatible with IEC60512 standard. Its shape design, material, performance and quality meet the standards of same kind of products made by foreign producers. K-BE rectangle high- current connector adopts reliable screw thread terminal so it makes the connection very easy. (The product has passed LR accreditation), CCC accreditation and CE accreditation.
Rectangle heavy-duty industrial connector 16-pin male core plug
Specifications:
Shell material |
Aluminum die casting alloy |
Surface treatment |
Plastic spraying |
Connection mode |
Screw thread terminal |
Cross-section of lead |
0.5 ~ 2.5mm AWG20-14 |
Rated voltage |
400V |
Rated current |
10A~16A |
Insulation resistance |
≥1000MΩ |
Withstand voltage |
3000V(1 min) |
Temperature range |
-40℃~ +125℃ |
Flame retardant rating |
UL 94-V0 |
Pollution level |
3(C) |
Overvoltage type |
Ⅲ |
Contact resistance |
≤1 MΩ |
Mechanical endurance |
≥500times |
Shell protection degree |
IP65 |
