Specifications
rfid hf inlay rfid inlay sheet s50 rfid inlayrfid hf inlay rfid inlay sheet s50 rfid inlay
HUAYUAN Smart could develop any size and shape of antenna that can be adapted to the specific requirements of the customer.
Customers can also select different sheet formats such as 3x7, 5x5,3x8,4x8,4x6,2x5,2x4 or other customized layouts.
HUAYUAN prelam is ideal semi-products for laminating contactless card,tag applications such as automated fare collection,access control, ePayment and identification.
Specification
| Operating Frequency | LF 125KHz, HF 13.56MHz, UHF GLOBAL 860MHz-960MHz |
| Standard | ISO14443,ISO15693,ISO 18000 |
| Material | PVC, PET,Paper |
| Dimension | 310mm x 468mm, Max. size 520mm x420mm, A4 210mm x297, |
| Layout | 3x7, 5x5,3x8,4x8,4x6, 2x5,2x4, or any Customization of CR80 card or any unit antenna size |
| Thickness |
HF normal 0.45mm,0.5mm, min.0.3mm , LF normal ,0.6mm, Min. 0.5mm UHF 0.6mm, 0.5mm |
| Antenna |
HF: AL Etching,Pre-winding Copper coil, Altrasonic Embeding; LF: Pre-winding Copper Coli, AL Etching; UHF: AL Etching |
| Bonding |
LF: Wire Bonding, HF: FLIP chip, Wire Bonding, MOA2, UHF: FlIP chip |
| Read range | more than 50mm with our reader |
| Working temperature | -25°C ~ +55°C |
| Store temperature | -25°C ~ +65°C |
About US
Shanghai Huayuan Smart Information Technology Co., Ltd. is one of the earlier specializing in the production of RFID (Radio Frequency Identification) card,inlay,tags, and reader modules. Our owned subsidiary locates in Shenzhen( Shenzhen Huayuan Smart Technologies Co., Ltd) have full sets of production line of RFID Products which have been approved by IC certification and ISO9001:2008 certification. Now hundreds of millions of pieces of RFID products have been supplied to our clients and partners around the world which have widely been used to security&protection, transportation, tourism, anti-counterfeiting, financial and others.
Our clients partners: Shanghai Metro Group, Zhejiang Highway Group,Tongji University, HP Incorporation, France Airport,Canada Airport,etc. More than 20years international business experiences to establish the long term business relationship with more than 100 countries and areas’ clients and partners. Different specification RFID cards,inlay,tags,labels and reader modules are provided to our customers.OEM & ODM service is available.
Our Production Facilities
Our Certificate
FAQ
1. Can we get free samples?
Yes - we offer free samples, with shipping and taxes paid by the buyer.
2. What is the lead time?
The lead time will be about 10 to 15 days with inlays, for other products please contact us for details.
3. What is the minimum order quantity?
The MOQ for dry inlays is 20000pcs, for wet inlays or labels is 5000pcs, for tamperproof inlays or tags is 1000pcs, for other special tags is 500pcs.
4. What is the payment term?
The payment term is T/T or paypal before shipment.
5. Are you looking for distributors?
Yes we offer distributorship to clients whose order amount of a single product exceeds 10,000,000pcs and will potentially do more similar purchases within certain period of time. Please contact us for further information.
